Home > Products > CONSTANTAN > CuNi Alloy Wire
CuNi Alloy Wire
                            Negotiable
                                                            / Kilogram


                                                50 Kilograms(Min. Order)

                    - SHANGHAI
 - T/T

You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | JS | |
| Model Number | CuNi23 | Type | Bare | |
| Application | Heating | Conductor Material | Other, CUNI ALLOY | |
| Conductor Type | Solid |
Product Description
Specifications
constantan wire :CuNi44, CuNi40, CuNi30, CuNi23,CuNI19,CuNi10, CuNi6, CuNi4, CuNi2, CuNi1size:10.0mm-0.03mm
ISO9001, ROHs
constantan wire :CuNi44, CuNi40, CuNi30, CuNi23,CuNI19,CuNi10, CuNi6, CuNi4, CuNi2, CuNi1
size:10.0mm-0.03mm
ISO9001, ROHS ,REACH
PACKING;COIL AND CARTON
DELIVERY TIME: 15-20 DAYS
| main property | type | CuNi1 | CuNi2 | CuNi6 | CuNi8 | CuMN3 | CuNi10 | CuNi14 | CuNi19 | CuNi23 | CuNi30 | CuNi34 | CuNi44 |
| main chemical composition | Ni | 1 | 2 | 6 | 8 | / | 10 | 14.2 | 19 | 23 | 30 | 34 | 44 |
| Mn | / | / | / | / | 3 | / | 0.3 | 0.5 | 0.5 | 1.0 | 1.0 | 1.0 | |
| Cu | rest | rest | rest | rest | rest | rest | rest | rest | rest | rest | rest | rest | |
working temperature °c  | 200 | 200 | 220 | 250 | 200 | 250 | 300 | 300 | 300 | 350 | 350 | 400 | |
| <100 | <120 | <60 | <57 | <38 | <50 | <38 | <25 | <16 | <10 | -0 | <-6 | ||
| melting point  °c  | 1085 | 1090 | 1095 | 1097 | 1050 | 1100 | 1115 | 1135 | 1150 | 1170 | 1180 | 1280 | |
| tensile mpa | >210 | >220 | >250 | >270 | >290 | >290 | >310 | >340 | >350 | >400 | >400 | >420 | |
elongation%  | >25 | >25 | >25 | >25 | >25 | >25 | >25 | >25 | >25 | >25 | >25 | >25 | |
| resistivity | 0.03±10% | 0.05±10% | 0.10±10% | 0.12±10% | 0.12±10% | 0.15±10% | 0.20 ± 5% | 0.25 ± 5% | 0.30 ± 5% | 0.35± 5% | 0.40 ± 5% | 0.49 ± 5% | |
| density g/cm3 | 8.9 | 8.9 | 8.9 | 8.9 | 8.8 | 8.9 | 8.9 | 8.9 | 8.9 | 8.9 | 8.9 | 8.9 | |
| conductivity | 145 | 130 | 92 | 75 | 84 | 59 | 48 | 38 | 33 | 27 | 25 | 23 | |
