BLVV 3.6/6kv LV 7/12/19cores PVC Insulated and Sheated Wire GB/T ASTM BS DIN Building Wire
- qingdao/shanghai/tianjinYJV 3.6/6kv MV 1/3/5cores 95/120/150mm XLPE/PVC Insulated GB/T G/ZL power cable
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
BLVV 3.6/6kv LV 1/3/5cores PVC Insulated and Sheated Wire GB/T ASTM BS DIN Building Wire
-
Building Wire ,house Wire ,power Cable 3x2.5
-
10mm Copper Conductor PVC Insulation Building Electric Cable Wire
-
BV 3.6/6kv LV 1/3/5cores Copper Conductor PVC Insulated GB/T JB Building Cable
-
BLV 450/750V LV 1/3/5cores GB/T JB Aluminium Conductor PVC Insulated Cable
-
BLVV 3.6/6kv LV 1/3/5cores GB/T JB Aluminium Conductor PVC Insulated and Sheated Round Cable
Product Details
| Place of Origin | Henan, China | Brand Name | Zhengzhou Hongliang | |
| Model Number | YJV | Insulation Material | PVC | |
| Type | Other, Medium Voltage, BLVV wires | Application | Construction | |
| Conductor Material | Aluminum | Jacket | PVC |
Product Description
Item Name: BLVV 3.6/6kv LV 7/12/19cores PVC Insulated and Sheated wire GB/T ASTM BS DIN building wire
IEC 60502, IEC 60228, IEC 60332, CE,
Armour, LSZH, Fire-resistant optional
Constructions BLVV 3.6/6kv LV 7/12/19cores PVC Insulated and Sheated wire GB/T ASTM BS DIN building wire
Conductor | Compact Stranded Copper Conductor, Class 2 as per IEC 60228 |
Circular solid Copper Conductor, Class 1 as per IEC 60228 | |
Flexible Stranded Copper Conductor, Class 5 as per IEC 60228 | |
Conductor Screen | Semi-conductor (MV only) |
Insulation | XLPE(Cross-linked polyethylene) |
Insulation Screen | Semi-conductor (MV only) |
Separate Screen | Copper Tape (MV must, LV optional) |
Filler | PP Yarn, or Paper |
Wrapping Tape | PP |
Inner Covering | Extruded PVC (MV only) |
Armour | Steel Wire, or Steel Tape, or Aluminium Tape optional |
Overall Sheath | PVC or PE |
Applications BLVV 3.6/6kv LV 7/12/19cores PVC Insulated and Sheated wire GB/T ASTM BS DIN building wire
Used for power transmission and distribution line with voltage rated at 35kV and below.Compared with PVC Insulated Power Cable, xlpe power cable boasts not only characteristics of excellent electricity, mechanism, heat and aging-resistant, environment stress-resistant and chemical corrosion-resistant, but also simple structure, light weight, no restriction by laying drop, and high temperature allowance for long-term working.
Standards BLVV 3.6/6kv LV 7/12/19cores PVC Insulated and Sheated wire GB/T ASTM BS DIN building wire
International: IEC 60502-2, IEC 60228
China: GB/T 12706.2-2008
Other standards such as BS,DIN and ICEA upon request
Technical data BLVV 3.6/6kv LV 7/12/19cores PVC Insulated and Sheated wire GB/T ASTM BS DIN building wire
Rated voltage: 0.6/1kV, 1.8/3kV, 6/10kV, 8.7/10kV, 8.7/15kV, 12/20kV, 21/35kV, 26/35kV
Maximum Conductor Temperature: under normal (90°C), emergency (130°C) or short circuit no more than 5 s (250°C) conditions.
Min. Ambient Temp. 0°C, after installation and only when cable is in a fixed position
Min. Bending Radius: 20 x cable O.D for single-core non-armoured cables
15 x cable O.D for single-core armoured cables
15 x cable O.D for multi-core non-armoured cables
12 x cable O.D for multi-core armoured cables
Certificates BLVV 3.6/6kv LV 7/12/19cores PVC Insulated and Sheated wire GB/T ASTM BS DIN building wire
CE, RoHS, CCC, KEMA and more others at request
Specifications BLVV 3.6/6kv LV 7/12/19cores PVC Insulated and Sheated wire GB/T ASTM BS DIN building wire
YJV | Copper Conductor, XLPE Insulated, PVC Sheathed Power Cable | For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed. |
YJLV | Al. Conductor, XLPE Insulated, PVC Sheathed Power Cable | |
YJY | Copper Conductor, XLPE Insulated, PE Sheathed Power Cable | For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed. |
YJLY | Al. Conductor, XLPE Insulated, PE Sheathed Power Cable | |
YJV22 | XLPE Insulated,Steel Tape Armored,PVC Sheathed Power Cable | Suitable for burying in ground, Able to bear external mechanical forces but large pulling forces. |
YJLV22 | Al. Insulated,Steel Tape Armored,PVC Sheathed Power Cable | |
YJV32 | Copper Conductor, XLPE Insulated, Fine Steel Wire Armored,PVC Sheathed Power Cable | Apply to shafts,water and soil,able to bear the larger positive pressure. |
YJLV32 | Al.Conductor, XLPE Insulated, Fine Steel Wire Armored,PVC Sheathed Power Cable | |
YJV42 | Copper Conductor, XLPE Insulated,Thick Steel Wire Armored,PVC Sheathed Power Cable | For laying in shaft, water underground and large diference of level, able to bear external mechanical pressure and moderate pulling force. |
YJLV42 | Al.Conductor, XLPE Insulated,Thick Steel Wire Armored,PVC Sheathed Power Cable |
Related pictures about BLVV 3.6/6kv LV 7/12/19cores PVC Insulated and Sheated wire GB/T ASTM BS DIN building wire
price high voltage dc power cable .
1) Packing length:100 to 1,000m reeled in carton drum or according to customers' requirement
2.By standard wooden drum or roll.
3.Drum size:1100mm*1100mm*1100mm.
or as your request.
BLVV 3.6/6kv LV 7/12/19cores PVC Insulated and Sheated wire GB/T ASTM BS DIN building wire
Henan Huadong Cable Co., Ltd Established in 2005, Henan Huadong Cable Co., Ltd is a joint stock enterprise integrated in cable production, research & development, and domestic & international trade. Our main products consist of power cables, bare conductors, aerial bundled cables, control cables, welding cables, rubber cables,
special cables and electrical wires. Our products are produced according to the standards of GB, IEC, BS, DIN, ASTM, JIS, NF,
AS/NZS, CSA and so on. Meanwhile we can produce based on customers' requirements and specifications.
Producing capacity each year: 320000 km .
Certificate BLVV 3.6/6kv LV 7/12/19cores PVC Insulated and Sheated wire GB/T ASTM BS DIN building wire
Our products are produced according to the standards of GB, IEC, BS, DIN, ASTM, JIS, NF, AS/NZS, CSA and so on.
Meanwhile we can produce based on customers' requirements and specifications
power cable Certificate:
The company has passed ISO90012008 quality certification, CCC China Compulsory Certification, National Electrical Product Safety Certification, State Construction and ProjectCommitee Recommended Manufacturer of the Transformation of Urban and Rural Power Grid Construction.
BLVV 3.6/6kv LV 7/12/19cores PVC Insulated and Sheated wire GB/T ASTM BS DIN building wire
1. We guarantee to offer new advanced goods.
2. We'd like to send skilled personnel to the installing place to help offer technical consultant, quantity estimation and instruction,
installing, preliminary testing,and help start up running; and to answer for any defect of the product found in installing and run testing,
If there's something wrong with the product, we'll give our answer within 12 hours and get to the spot within 36 hours.
3.After installaton, We'll send skilled personnel to have the preliminary test and answer for any problems emerged. We take the whole charge of the fee needed in repairing,testing or retesting within the scope of our duty required in contract.
4.During the contract's period of validity,of the project must be started all over again or the goods can not be used at all which is resulted from
our faulty goods and improper files or mistakes made by our instructors, we'll change the goods at once without compensation and
take charge in all expenses of reinstallation.
8.Notice:we can produce the product according to customer's requirment.
Short delivery time and quotation at once.
free samples are available for further evaluation and you are highly welcome to visit our factory anytime!!
