Product Details
| Place of Origin | Henan, China | Brand Name | Zhenzhou hongliang cable | |
| Model Number | Control Cable | Insulation Material | PVC | |
| Type | Low Voltage | Application | Industrial | |
| Conductor Material | Copper | Jacket | PVC |
Product Description
Item name: CYKY-J O Cable 1.5mm 2.5mm 4mm 6mm 450/750V PVC insulation PVC sheath control cable .
1. Application of CYKY-J O Cable 1.5mm 2.5mm 4mm 6mm 450/750V PVC insulation PVC sheath control cable :
Used for power transmission and distribution line with voltage rated at 35kV and below.Compared with PVC Insulated Power Cable, xlpe power cable boasts not only characteristics of excellent electricity, mechanism, heat and aging-resistant, environment stress-resistant and chemical corrosion-resistant, but also simple structure, light weight, no restriction by laying drop, and high temperature allowance for long-term working.

2. Technical data of CYKY-J O Cable 1.5mm 2.5mm 4mm 6mm 450/750V PVC insulation PVC sheath control cable :
| Code | PVC insulation PVC sheath CYKY cable 450/750V |
| Standarts | CSN 347656, CSN 347615 |
| Construction | 1- Solid or Stranded Copper Conductor |
| 2- PVC insulation 3- PVC Filling, 4- PVC outer sheath | |
| Application | Fixed wiring in dry and damp premises, in conduits, on or under plaster and on |
| insulators over plaster, switching and distribution panels. | |
| Technical Data | Max. operating temperature 70 ºC Short circuit temperature 160 ºC |
| Manufacturer | Zhengzhou Hongliang Cable. |

3. Executive standard :
International: IEC 60502-2, IEC 60228
China: GB/T 12706.2-2008
Other standards such as BS,DIN and ICEA upon request
Model  | Name  | Voltage V  | Number of cores  | Cross-sectional area mm2  | Range of application  | |
KVV  | Copper core PVC insulated PVC sheathed control cable  | 450/750  | 4-37  | 0.75-10  | For laying indoors, in cable trench, pipelines and other fixed occasion  | |
KVV22  | Copper core PVC insulated PVC sheathed steel tape armored control cable  | 450/750  | 4-37  | 0.75-10  | For laying indoors, in cable trench, directly buried pipeline and other fixed occasion, also can bear larger external mechanical forces  | |
KVVP  | Flame retardant copper core PVC insulated PVC sheathed control cable  | 450/750  | 4-37  | 0.75-10  | For laying indoors, in cable trench, pipelines, etc, and somewhere that need fixed installation  | |
KVVR  | Soft copper core PVC insulated and sheathed control cable  | 450/750  | 4-37  | 0.75-10  | For laying indoors, where there is a requirement for mobile  | |
KVVRP  | Copper core PVC insulated PVC sheathed braided shielding control cable  | 450/750  | 4-37  | 0.75-10  | For laying indoors, where there is a requirement for mobile screen  | |
ZRKVV  | Flame retardant copper core PVC insulated PVC sheathed control cable  | 450/750  | 4-37  | 0.75-10  | For laying indoors, in cable trench, pipe fixed occasion where demands such as flame retardant  | |
ZRKVV22  | Flame retardant copper core PVC insulated PVC sheathed woven tape armored control cable  | 450/750  | 4-37  | 0.75-10  | For laying indoors, in cable trench, pipes, burying and etc. There is a requirement for flame retardant can bear external mechanical forces larger fixed occasion  | |

4. Picture show CYKY-J O Cable 1.5mm 2.5mm 4mm 6mm 450/750V PVC insulation PVC sheath control cable :
CYKY-J O Cable 1.5mm 2.5mm 4mm 6mm 450/750V PVC insulation PVC sheath control cable .
International wooden drums or as your requirement.

300/500V KVV control cable PVC insulation PVC sheath 2x2.5mm2 16x2.5mm2 30x2.5mm2 manufaturer .
Zhengzhou Hongliang Cable Co.,ltd is one of the branch of Huadong Cable Group ,and also is biggest professional import and export trade company in China.
    The plant was founded in 1998, occupied 50,000 square meters,with advanced equipments of 20 sets production lines and 25 sets testing machines,Annual production capacity is more than 12 million kilometers.
Our international branch is located in Zhengzhou city,which is well-known for convenient transportation . We mainly produce and export power cable, all aluminum conductor(AAC), aluminum conductor steel reinforced(ACSR Conductor), all aluminum alloy conductor(AAAC), overhead Aerial bundled ABC cable,1-66kV power cables(including XLPE insulated cables, PVC insulated cables, SWA/STA armored cables).(XLPE/PVC insulated ABC cable),control cable, welding cable, rubber cable ,mining cables and electrical wires(PVC sheathed flexible cable). These cables can be used for power transmission in air,underground and industry,such as power station, railway, agriculture, and estate. Our products honoured I S O 9 0 0 1:2 0 0 2 and CCC,PCCC,SGS,BV certificates. We strictly according to GB,IEC,BS,ICEA, ASTM, DIN, VED, JIS standards to manufacture the products, and also we can design and produce according to customers' requirements.We have exported wires and cables to European, South America, North America, Middle East, Africa, Asia,,Oceania countries and etc.
CYKY-J O Cable 1.5mm 2.5mm 4mm 6mm 450/750V PVC insulation PVC sheath control cable .
1.Quality is our culture. we are one of the most famous brand in China. Quality is verified by clients.
2. High-effiency oversale team makes your business much easier.
3. free samples are available for further evaluation and you are highly welcome to visit our factory anytime!

1.what is our payment term ?
Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.
2.what is the lead time ?
The lead time usually is 10 - 30 working days.
3.what is the package of the cable ?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.
4.Could we provide the free sample for customer ?
Sure, we provide the free sample for customer to checking.
Your best friend Fiona is always here waiting for your inquiry.
CYKY-J O Cable 1.5mm 2.5mm 4mm 6mm 450/750V PVC insulation PVC sheath control cable .
