B-X Model High Efficiency Grinder
- Shanghai
You May Like
Product Details
| Condition | New | Type | Internal Grinding Machine | |
| CNC or Not | Normal | Place of Origin | Jiangsu, China | |
| Brand Name | Lemar | Model Number | B-X | |
| Power(W) | 6.25Kw | Certification | ISO/ BV | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Description of Grinder
This machine has widely application and is widely used for pharmaceutical industry, chemical industry, pesticide industry foodstuff industry, grain industry and so on.
This machine used the relative motion between movable and fixed teeth disc, the raw materials to be crushed undertakes the comprehensive actions such as impacted by teeth, friction, impacted between raw materials, finally the raw materials are crushed, Its features are simple and solid in structure, stable in operation, high in crushed efficiency. The crushed raw material can be discharged through the grinding chamber. Moreover, different size of raw material to be crushed can be got through changing screen with different mesh. 30B model is in all stainless steel. The surface of all the cabinet wall is smooth by machining to insure the medicine, food and chemical production can meet national standards to GMP requirements.
Principle of structure and its function of Grinder
The grinder set consists of grinder, EXC collector of raw material and ESC collective duster. It solves the problem of the dust is flying during the period of crushing raw material.
The principle of work is as follows: after raw material is fed into the crushing chamber, it undertakes the comprehensive actions such impacted by teeth, shearing force, friction force, impacted between raw materials are crushed. Through sieving. The needed powder can be got.
The grinder, collector of raw material and ESC collective duster are all made of stainless steel and are in conformity with the requirements of GMP.
Technical parameters
Model | Unit | 20B/20B unit | 30B/30B unit | 40B/40B unit | 60B/60B unit |
Capacity | kg/h | 60-150 | 100-300 | 160-800 | 500-1500 |
Revolution of Spindle | r/min | 4500 | 3800 | 3400 | 2800 |
Size of Feed Material | mm | 6 | 10 | 12 | 15 |
Size of Grinded Material | mesh | 60-150 | 60-120 | 60-120 | 60-120 |
Size of Grinded Motor | kw | 4 | 5.5 | 11 | 15 |
Power of Dust-catching Motor | kw | 1.5 | 1.5 | 1.5 | 2.2 |
Overall Dimensions(L×W×H) | mm | 550×600×1250 | 600×700×1450 | 800×900×1550 | 1000×900×1680 |
Overall (Unit) Dimensions(L×W×H) | mm | 1100×600×1650 | 1200×650×1650 | 1350×700×1 700 | 1550×1 000×1750 |
