Home > Products > Comprehensive Products > Ameison 900 MHz 6 DBi Omnidirectional Antenna RFID Antenna GSM Antenna Integral N-Type Female Connector
Ameison 900 MHz 6 DBi Omnidirectional Antenna RFID Antenna GSM Antenna Integral N-Type Female Connector
- Shenzhen Hongkong
 - T/T Credit Card

You May Like
-


2x18 DBi High Gain Vertical and Horizontal Polarization 5.8GHz Wifi MIMO Wireless WLAN Antenna
 -


Ameison Dual Polarized 15 DBi 5.8G Antenna
 -


Ameison 3ghz 1920-2170mhz Magnetic Base Antenna Car Antenna
 -


Ameison 2.4ghz Magnetic Base Antenna Car Antenna
 -


2x18 DBi High Gain Vertical and Horizontal Polarization 5.8GHz Wifi MIMO Antenna
 -


Ameison 2.4/5.8 GHz 3 DBi Multi-band Rubber Duck Antenna -SMA Male Connector

Product Details
| Place of Origin | Guangdong, China | Brand Name | Ameison | |
| Model Number | AMXF-9092-6 |
Comply with export safe package.
Product Description
Specifications
900MHz Omni Fiberglass AntennaFactory price
Lightweight fiberglass radome
Provided wifh dual u-bolt mast mounting kit
Ameison 900 MHz 6 dBi Omnidirectional Antenna
Model No.: AMXF-9092-6
The Ameison AMXF-9092-6 is a high performance omnidirectional antenna designed for the 900 MHz ISM band. It is ideally suited for multipoint, Non Line of Sight (NLOS) and mobile applications where high gain and wide coverage is desired. Typical applications include 900MHz Wireless LAN, SCADA, Wireless Video Links and 900MHz Cellular band applications.
This antenna features an integral N-Female type connector that mounts through the wall of an equipment enclosure. Included with the AMXF-9092-6 is a dual u-bolt mast mounting kit. Consisting of a heavy-duty steel bracket and a pair of U-bolts, this kit allows installation on masts up to 50mm in diameter.
This omni antenna’s construction features a rugged 20mm diameter fiberglass radome for durability, aesthetics and long service life. It is designed for all weather operation.
For additional information and complete specifications, please check the data sheet below.
Features:
- Superior all weather performance
 - Rugged industrial grade design
 - Lightweight fiberglass radome
 - Integral N-Female connector
 - Heavy-duty steel mounting bracket

- 900MHz ISM Band
 - Wireless LAN systems
 - Multipoint applications
 - Non Line of Sight (NLOS)
 - GSM

AMXF-9092-6 Electrical Specifications  | |
Frequency range(MHz)  | 902-928  |
Bandwidth(MHz)  | 26  |
Gain(dBi)  | 6  |
Half-power beam width(°)  | H:360 V:25  |
VSWR  | ≤1.5  |
Input Impedance(Ω)  | 50  |
Polarization  | Vertical  |
Maximum input power(W)  | 100  |
Lightning protection  | DC Ground  |
Input connector type  | N Female or Requested  |
Mechanical Specifications  | |
Dimensions (mm)  | Φ20*800  |
Antenna weight(kg)  | 0.46  |
Operating temperature(°c)  | -40~60  |
Rated Wind Velocity(m/s)  | 60  |
Radome color  | Gray  |
Mounting way  | Pole-holding  |
Mounting hardware(mm)  | Φ35-Φ50  |
Product Picture
