Product Details
| Condition | New | Elevation Speed | 8.5 sec | |
| Vertical Travel(mm) | 1000 mm | Horizonal Travel(mm) | 1500 mm | |
| Application | Other, Take out Product | Place of Origin | Guangdong, China | |
| Brand Name | BORUNTE | Model Number | BRB1000WS-S2 | |
| Weight | 245 kg | Dimension(L*W*H) | 2110*1340*1480 mm | |
| Power(W) | 1.7 KVA | Certification | CE, ISO, SGS, TUV | |
| Warranty | One year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Robotics And Automation
1.About Product
Telescopic type and single arm , suitable for two plate mold products take out. Traverse axle
and vertical axle driven by AC servo motor.
Main Specification
| Model | BRB1000WS-S2 | BRB1200WS-S2 |
| Power Source(KVA) | 1.7 | |
| Recommended I.M.M(ton) | 250-450 | 450-650 |
| Traverse Stroke(mm) | 1500 | 1800 |
| Traverse Driven | AC Servo Motor | |
| Crosswise Stroke(mm) | 400 | 400 |
| Vertical Stroke(mm) | 1000 | 1200 |
| Max.Loading(kg) | 8 | 8 |
| Dry Take Out Time(sec) | 1 | 1.2 |
| Dry Cycle Time(sec) | 8.5 | 9 |
| Air Consumption(Nl/cycle) | 10 | 10 |
| Net Weight(kg) | 245 | 360 |
2.Outer Dimensions
3.Controller and Accessories
We use high quality end of arm tooling parts on. And we promise that if any part is broken in
the warranty time , we can change it free, just need you send the old one .
4.About Our Company
Our company is the first listed company of this line in China . There are advanced processing
equipment, standardized assembling process, scientific testing method and modern storge bin.
We join in the second large exhibition of this line in the global on 23th-26th in Shanghai.

Our business involves various markets all over the word, in many fields with our excellent
product performance; we favored consistent high praise from domestic and foreign customers.
