Product Details
| Condition | New | Type | Ball Mill | |
| Motor Type | AC Motor | Power(W) | 18.5kw | |
| Capacity(t/h) | 0.65-2 | Place of Origin | Henan, China | |
| Brand Name | Baichy | Model Number | 900*1800 | |
| Weight | 3.6t | Certification | ISO9001:2008 | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.Hot sale famous Grinding Ball Mill2.Low consumption
3.Long service life
4.Simple structure&easy maintenance
5.ISO9001
CE Approved Grinding Ball Mill From Baichy Machinery
1. Structure of Ball Mill:
The ball mill is composed by feeding part, discharing part, rotation part and driving part(reducer, small driving gear, electric motor and electric control).
Balls in Cylinder
2. Applications of Ball Mill:
1) Size reduction of various materials
2) Feed sizes of 25mm to product sizes of 0-400mesh
3) Wet or dry grinding
4) Continuous grinding process
5) Mineral processing
6) Environmental grinding
3. Working Principle of Ball Mill:
When the ball mill turning, there are centrifugal force and force of friction between grinding medium and the plate in the rotary body wall. And the grinding medium will rotate with rotary body to a certain height. Then it will fall freely under gravity, whereabouts of grinding medium, like a projectile impact the material at the bottom to smaller size. In addition, grinding medium also generates sliding and rolling in the rotary process. Thus there are schleifwirkung among grinding medium, plate and material. So we can get fine powder in the process.
4. Main Technical Parameters of Ball Mill:
Model | Rotational speed (r/min) | Ball weight (t) | Material-in size(mm) | Material-out size(mm) | Capacity (t/h) | Motor power (kw) | Weight (t) |
Φ 900 × 1800 | 38 | 1.5 | ≤ 20 | 0.075 -0.89 | 0.65 -2 | 18.5 | 3.6 |
Φ 900 × 2100 | 38 | 1.3-1.4 | ≤ 15 | 0.075 -0.83 | 0.7 -3.5 | 18.5 | 3.9 |
Φ 900 × 3000 | 38 | 2.7 | ≤ 20 | 0.075 -0.89 | 1.1-3.5 | 22 | 4.5 |
Φ 1200 × 2400 | 32 | 3.8 | ≤ 25 | 0.0745-0.6 | 1.5-4.8 | 30 | 11.5 |
Φ 1200 × 2800 | 32 | 3.3-3.5 | ≤ 25 | 0.0745-0.6 | 2-6 | 30 | 13 |
Φ 1200 × 4500 | 32 | 7 | ≤ 25 | 0.074 -0.4 | 1.6-5.8 | 45 | 13.8 |
Φ 1500 × 3000 | 27 | 8 | ≤ 25 | 0.074 -0.4 | 2-5 | 75 | 17 |
Φ 1500 × 3500 | 27 | 5.75-6.4 | ≤ 25 | 0.075 -0.4 | 3-7 | 75 | 17.5 |
Φ 1500 × 4500 | 27 | 14 | ≤ 25 | 0.074 -0.4 | 3.5-12 | 110 | 21 |
Φ 1500 × 5700 | 27 | 15 | ≤ 25 | 0.074 -0.4 | 3.5-8 | 115 | 24.7 |
Φ 1830 × 3000 | 24 | 18 | ≤ 25 | 0.074 -0.4 | 4-10 | 130 | 28 |
Φ 1800 × 3600 | 24 | 10.6-11.35 | ≤ 25 | 0.075 -0.4 | 5-22 | 130 | 33.5 |
Φ 1830 × 7000 | 24 | 25 | ≤ 25 | 0.074 -0.4 | 7.5-17 | 210 | 36 |
Φ 2100 × 3600 | 22 | 14-15.2 | ≤ 25 | 0.075 -0.4 | 15-36 | 370 | 46.8 |
Φ 2200 × 5500 | 21 | 30 | ≤ 25 | 0.074 -0.4 | 10-20 | 210 | 48.5 |
Φ 2200 × 6500 | 21 | 31 | ≤ 25 | 0.074 -0.4 | 14-26 | 380 | 52.8 |
Φ 2400 × 3000 | 20.6 | 15.5-16.6 | ≤ 25 | 0.075 -0.4 | 22-24 | 245 | 59 |
Φ 2400 × 4500 | 21 | 30 | ≤ 25 | 0.074 -0.4 | 8.5-60 | 380 | 65 |
Φ 2700 × 3600 | 20.6 | 39 | ≤ 25 | 0.074 -0.4 | 12-70 | 400 | 91.3 |
Φ 3200 × 4500 | 18 | 65 | ≤ 25 | 0.075-0.4 | according to the technics | 800 | 137 |
