hot sale steel coil slitting and rewinding machinery price

hot sale steel coil slitting and rewinding machinery price

Specifications

1.slitting line machine

2.steel sheet slitting line machine

3.slitting line for steel plate

tal coil slitting line machine

5.slitting machine for sale

2.main parameter table.

1. 1. Thickness of coiled plate: δ=0.3—3mm; δ b≤380Mpa;

2. 2. Width of coiled plate: slitting 1800mm;
3. 3. Precision of slitting: width tolerance: ±0.1mm;
4. 4. Slitting speed: 0—50m/min(adjustable) ;
5. 5. Loading capacity of uncoiler: 20T;
6. 6. Coil I.D:  Ø508mm—Ø610mm; two-step pattern
7. 7. Coil O.D: ≤ Ø1600mm;
8. 8. Main shaft diameter of slitter:  Ø240mm; material 40Cr;
9. 9. Width of slitting steel: ≥35mm;
10. 10. Slitting blade:  Ø240×350×15; 42 pcs, cutting strips: 20 pcs;
11. 11. Material of slitting blade: 6CrW2Si;
12. 12. Hardness of blade: HRC58—60;
13. 13. Recoiler I.D:  Ø508mm, loading capacity: 20T

3.standard component:

 4.Product:

We can customize the products according to customer ' s requirements

:

 7.Application:

8.company advatage:

1)we have about 12 years experience in the steel roll forming machines for the design and produce there are much experience and professional people.

2)quality control,we have CNC process to produce the rollers,grinder machine to smooth the frame.make more precise.and less tollerance.and after assebling,inspect the whole machine and result before delivery.

3)we have professional engineer in charge of installation abroad.after services are easy way solution.

4)on time delivery.

5)quality garantee,one year time garantee,and service all the life.
