Hot Roll Metal Slitting Line With Decoiler and Recoiler
US$ 50,000 - 150,000
/ Set
1 Set(Min. Order)
- ningbo/shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Metal Slitting Line With Decoiler and Recoiler
-
Automatic Steel Slitting Machine With Hydraulic Decoiler
-
Steel Coil Slitting Line With Decoiler and Recoiler
-
Steel Used Coil Slitting Line With Decoiler and Recoiler
-
Metal Slitting Line Machine With Decoiler and Recoiler
-
Hot Roll Metal Slitting Line With Decoiler and Recoiler
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | bluesteel | Model Number | slitting line | |
| Voltage | 380V 3phase 50hz | Rated Power | 300kw | |
| Dimension(L*W*H) | 36*2.2*2.2M | Weight | 50000kgs | |
| Warranty | 14months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
roll forming machine/slitting linestrong materal
high speed
plc control with automatic
roll forming machine/slitting line
Material of processible coiled plate: apply for carbon steel plate δ b≤380Mpa;
- 1. Thickness of coiled plate: δ=0.3—3mm;
- 2. Width of coiled plate: slitting 1800mm;
- 3. Precision of slitting: width tolerance: ±0.1mm;
- 4. Slitting speed: 0—50m/min(adjustable) ;
- 5. Loading capacity of uncoiler: 20T;
- 6. Coil I.D: 508mm—610mm; two-step pattern
- 7. Coil O.D: ≤1600mm;
- 8. Main shaft diameter of slitter: 240mm; material 40Cr;
- 9. Width of slitting steel: ≥35mm;
- 10. Slitting blade: D240×D350×15; 42 pcs, cutting strips: 20 pcs;
- 11. Material of slitting blade: 6CrW2Si;
- 12. Hardness of blade: HRC58—60;
- 13. Recoiler I.D: D508mm, loading capacity: 20T
