High Quality Automatic Aluminium Corrugated Wall And Roof Sheet Roll Forming Making Machine For Sale
- ningbo/shanghai for wall and roof roll forming machine
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Corrugated Roof Roll Forming Machine / Galvanized Roll Forming Machine/aluminium Roll Forming Machine
-
Corrugated Sheet Metal Roof Making Machine Prices, Aluminium Roofing Sheet Making Machine
-
Protable Metal Roofing Sheet Roll Forming Machine / Zinc Roofing Roller Former Maker
-
Galvanized Corrugated Steel Roof Tile Cold Roll Forming Machine, Roof Roll Former, Roofing Sheets Making Machine
-
Corrugating Iron Cold Galvanizing Roof Forming Machine, Aluminium Roofing Sheet Forming Making Machine
-
New Condition Corrugated Iron Roofing Sheet Roll Forming Machine / Corrugated Roof Tile Making Machinery
Product Details
| Condition | New | Type | Tile Forming Machine | |
| Tile Type | Colored Glaze Steel | Use | Roof | |
| Production Capacity | 10-25m/min | Place of Origin | Zhejiang, China | |
| Brand Name | bluesteel | Model Number | bl | |
| Power(W) | 8.5kw | Voltage | 380V 3phase 50Hz. | |
| Dimension(L*W*H) | 15*1.5*1.5M | Weight | 8000KGS | |
| Certification | ce | Warranty | 14months for wall and roof roll forming machine | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
High Quality Automatic Wall And Roof Sheet Roll Forming Machine For Sale
Specifications
1.roll forming machine
2.wall androof roll forming machine
3.high quality roll forming machine
4.wall and roof roll forming machine for sale
5.automatic wall and roof roll forming machine
1. roll forming machine machine workflow
2.roll forming machine main parameter table.
Material thickness | 0.3~0.7mm |
Material yield stress | 230~550 Mpa |
Max. forming speed | 8~25m/min |
Roller material | 45# steel with chrome treatment |
Roller driven type | Chain transmission |
Controller & operation | PLC & touch screen and button |
Hydraulic system pressure | 12 Mpa |
Hydraulic station motor power | 3 Kw |
Main motor power | 4~7.5Kw |
Total power | 7~10.5Kw |
Total weight | About 6000~8000 Kgs |
3.Roll forming machinestandard component:
4. roll forming machine Product:
We can also customize the products according to customer ' s requirements
6. roll forming machine Loading photos:
7. roll forming machine Application:
8.company advatage:
1)we have about 12 years experience in the steel roll forming machines for the design and produce there are much experience and professional people.
2)quality control,we have CNC process to produce the rollers,grinder machine to smooth the frame.make more precise.and less tollerance.and after assebling,inspect the whole machine and result before delivery.
3)we have professional engineer in charge of installation abroad.after services are easy way solution.
4)on time delivery.
5)quality garantee,one year time garantee,and service all the life.
