Automatic Plastic Case Depalletizer (XXD40)

Plastic crate depalletizer is a fully automatic packaging equipment to transfer the full plastic cases to conveyer for next procedure, the equipment include case conveying platform, pallet conveyor, pallet magazine, pallet conveying roller device. This machine is suitable for beer, beverage industry and foodstuff industry to put recycling bottle cases on production line.

2.   Equipment datasheet



3. Competitive Advantage:
3.1 Inspection device is set for inspecting the storage of cases on conveyor, automatic speed regulation according to inspection data.
3.2 The safety device can stop machine and alarm automatically in any emergency.
3.3 Simple configuration and easy maintenance.
3.4 High automation and intelligence.

4. Main structure and principle
4.1 Pallet conveyor:
Usingφ89 carbon steel or stainless steel pallet roller conveyor, side plate made of high quality carbon structural steel and surface baking finish and anti-rust, using Harbin or NSK bearing, pallet protection for front and back position of forklift.
Sensor control, it will stop when there is no pallet, to saving energy.
4.2  Depalletizing
The structure simple, compact and high efficiency, stable performance, easy adjustment when changing pack size, can satisfy different customer requirements.
The main machine moving wheel choosing Sweden FAG brand, main driving shaft choosing good brand, linear bearing using (Taiwan Jinheng), to ensure long term and stable running.
4.3 Conveying platform, adopt stainless steel chain, high efficiency and stable.
4.4 Flat-top chain output.
4.5 Pallet dispenser
It can release from full pallet and collect for each single empty pallet, can store 10-15 pallets.
4.6 Simple structure and easy to maintain, control cabinet doors are fitted with sealing strip, with good quality ventilation and filtration device. It equipped with multi-layer alarm indicator, the touch panel can display a different fault (fault to be reset, automatic fault reset, running indication etc.) The program design is reasonable, function of fault indicating. The machine will stop when the pallet falling and loosing.
4.7 It can stop and alarm automatically when the machine is in an abnormal situation.
4.8 Warning signs posted, to improve the safety awareness of the operator.

5. Applied Product:
