Teflon Seal Rotating Evaporator ISO Certificate Hot Selling

Model

R-1001-VN

R-1001-LN

R-1002-VN

R-1002-LN

Rotary speed(Rpm)

10-180

Evaporating speed(ml/min)

20

Achievable vacuum(Pa)

399.9 (below 3mmHg)

Temperature range(°C)

Room temp-100

Temperature display

Keypad input Digital display

Speed-setting

Knob setting ,Digital display

Safety functions

Insurance

Functions of lifting table

Weight balancing Gliding elevating+ manual lifting

Weight balancing

Rotary motor(W)

25

Heater wattage(KW)

1.5

Condenser model

Vertical type water refrigerating

Lean type water refrigerating

Vertical type water refrigerating

Lean type water refrigerating

Rotary bottle(L)

0.5-2

Collecting bottle(L)

1

Vacuum sealing

Double sealing rings made of Teflon+ Vinton materials

Water Bath size and volume(L)

φ260×140·7.4

φ240×142·6.3

Elevating stroke(mm)

100+150

120

Ambient temperature(°C)

5-35

Dimensions     (mm)

560L×320W×660H

750L×320W×540H

560L×320W×660H

750L×320W×540H

Weight

(kg)

9.5

8.5

Power Supply(V/Hz)

220/50

Model

R-1005

R-1010

R-1020

R-1050

Rotary Bottle

5L,diameter of flange opening: Φ50mm

10L,diameter of flange opening:Φ95mm

20L, diameter of flange opening:Φ95mm

50L,diameter of flange opening:Φ125mm

Collecting bottle

3L

5L

10L

20L

Speed-regulationj ofmain machine

Digital display, variable frequency, stepless Speed-regulation

Rotary speed of mainMachine

10to140r/min,digital display of rotary speed

10to130r/min,digital display of rotary speed

10to130r/min,digital display of rotary speed

10to110r/min,digital display of rotary speed

Rotaring motor       (W)

40W AD induction motor,power:40W

90W AD induction motor,power:90W

180W AD induction motor,power:180W

180W AD induction motor,power:180W

Condensing tube

Vertical type water refrigerating

Standing, main+auxiliary cooling and highly effcient3 circulating coldtrap

Heating boiler

stainless water bath

Temperature control

Digital display, temperature control,0~99°C

Achievable vacuum

399.9Pa (below 3mmHg)

Evaporating capability

Water≥2L/h Alcohol≥6.5L/h

Water≥3.2L/h Alcohol≥6.5L/h

Water≥5L/h Alcohol≥11L/h

Water≥9L/h Alcohol≥19L/h

Elevating function

Electric elevation

Electric elevation

Electric elevation

Electric plus manual lifting

Elevating stroke

0~150mm

0~160mm

0~190mm

0~230mm

Rated power supply

220V/50Hz

380V/50Hz

Power of power supply

2.2KW

4.8KW

6.3KW

8.3KW

Dimensions (mm)

765L*400W*1070H

920L*550W*1700H

1250L*600W*2100H

1320L*770W*2340H
