Home > Products > Low-temperature Cooling Liquid Circulating Pump > 5L minus 20 degree low temp cooling liquid circulating pump circulating refrigeration system DLSB-5/20
5L minus 20 degree low temp cooling liquid circulating pump circulating refrigeration system DLSB-5/20
- 1000 Set / Sets per Month
- Shanghai Dalian Qingdao etc.
- Credit Card
You May Like
-
5L minus 20 degree low temp refrigerated circulator DLSB-5/20 for Soxhlet Extraction Experiment
-
refrigerated circulator DLSB-5/20 with 5L Stainless Steel Bath
-
refrigerated circulator DLSB-5/20 with 12L/min Flow
-
DLSB-20L/-30 Low-temperature Refrigerated Circulator Recyclable Chiller
-
Minus 30 Celsius to Room Temperature DLSB-20L/-30 Refrigerated Circulator Recyclable Chiller
-
Minus 30 Celsius to Room Temperature Recyclable Water Chiller
Product Details
| Type | Cooler | Place of Origin | Henan, China | |
| Brand Name | Zhengzhou Great Wall | Model Number | DLSB-5/20 | |
| Certification | Other, ISO 9001:2008 |
Product Description
Specifications
DLSB-5/20 refrigeration circulator1. imported compressor
2. lowest temp: minus 20 degree
3. 12L/min, 5~7m lift
5L minus 20 degree low temp cooling liquid circulating pump circulating refrigeration system DLSB-5/20
CHARACTERISTICS OF USES:
Adoption of low-temperature liquid circulation equipment of compression refrigeration methods can cool the tube, the reaction bottles directly and so on to have chemical reaction under low-temperature and store chemical and biological products under low-temperature. Besides, it can also be combined with Rotary Evaporator, Vacuum Freeze-drying Box, Multi-purpose Circulating Water Vacuum Pump.
1. Large-capacity open bath combined with outside loop can not only be used as freezing tanks, but also provide cooling fluid outside
2. Digital setting and display of temperature, easy to operate.
3. Refrigeration compressors and other key parts adopt products with famous brands of the United States, Germany, and France and have high reliability and efficiency
4. Circulating system adapts SUS 304, 316 and macromole anti corrosion substance, which can prevent rust, corrosion, and low temperature liquid pollution
Technical data:
Model | DLSB-5/20 | |
Temperature range(°C) | -20~Room temp | |
Temperature stability(°C) | ±2 | |
Cooling capacity (W) | 10°C | 1150 |
0°C | 880 | |
-10°C | 600 | |
-20°C | 320 | |
Flow(L/min) | 12 | |
Lift(m) | 5~7 | |
Bath volume(L) | 5 | |
Bath opening(mm) | 210×180 | |
Ambient temperature(°C) | 5~25 | |
Power Supply(V/Hz) | 220/50 | |
Overall Power(W) | 600 | |
MaterialsOf Machine Casing | SPCC steel with powder coating | |
Dimensions(mm) | 465L×325W×730H | |
Weight(kg) | 41 | |
ISO 9001:2008 Certificate:
Recommended total system:
2012 Fairs:
Welcom to our factory:
