High Viscosity Roller Mill
- 200 Set / Sets per Month
- Shanghai China
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Other, Three Roller Mills | |
| Product Type | Other, Paint, Printing Ink, Ink | Place of Origin | Shanghai, China | |
| Brand Name | ELE | Model Number | EGM-65 High Viscosity Roller Mill | |
| Voltage | 380V, 220V, 415V | Power(W) | 0.75KW | |
| Weight | 100KGS |
Product Description
Specifications
1.Three roller machine2.Material:hard-wearing alloy
3.Apply to pigment, ink, paint ect. for high viscous material
4.CE
Three Roller Mill, Paint Three Roller Mills, High Viscous Mill, Grinding Machine, Ink Milling Machine, High Viscosity Roller Mill
Description
This machine applies to product with high viscosity or paste which is poor mobility and need high fineness requirement, After our constantly improve and optimize, EL developed EGW series three rollor mill with unique performance in production. Rollor is made of hard wearing alloy, the rollor is driven by motor, three rollers have three working position under working.
Features
1. Break away from each other, easy to clean
2. Two rollers tightly together and one roller break away appply to mix the material
3. Three rollors tightly together apply to disperse and discharge
Technique Paramters
Model | Power (kw) | Roller (mm) | Fast rollers speed (rpm) | Low speed (rpm) | Middle speed (rpm) | High speed (rpm) | Height of discharge port (mm) |
EGM-65 | 0.75 | 136 | 145 | 70 | 26 | 85 | 220 |
EGM-150 | 2.2 | 300 | 182 | 78 | 34 | 600 | 530 |
EGM-260 | 7.5 | 675 | 183 | 64 | 22.5 | 2368 | 530 |
EGM-405 | 15 | 810 | 130.5 | 42 | 13 | 5200 | 760 |
EGM-405II | 22 | 1000 | 408 | 153 | 58 | 2000 | 760 |
We have CE certificate.
