Home > Products > Cloth Inspecting Rolling Machine > Fabric Inspecting Rolling and Gauging Machine
Fabric Inspecting Rolling and Gauging Machine
- 65 Set / Sets per Month
- Shanghai Ningbo
- T/T Credit Card PayPal
You May Like
-
Fabric unwinding and loosening machine
-
Fabric /Cloth Inspection Machine Made in China
-
Wide Needle Inspection Machine Cloth Needle Machine Shenghe Brand
-
Flated Fabric Inspection Machine Cloth Inspection Machine
-
Tension Control fabric /nonwoven/textile/ Inspection Machine
-
Automatic Fabric Inspection and Rolling Machine Manufacturer
Product Details
| Place of Origin | Jiangsu, China | Brand Name | ShengHe | |
| Model Number | SH-861 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Fabric Inspecting Rolling and Gauging Machine1.Unneed frequent adjustment
2.Longlife&srevice
3.Easy control output
Fabric Inspecting Rolling and Gauging Machine
Usage:
Its for the material inspection, volume, also suitable for composite material volume. According to customer needs can be configured width shear device, to get ideal width matericals.
Feature:
1. The machine adopts channel, check a frame, compact structure, smooth operation, cover an small area. High applicability and appearance.
2. Adopts stepless motor, speed stepless, can watch in certain scope free speed, easy to operate. With computer control plan, can always read length value, convenience in site management.
3. Infared photoelectricity’s edge, hydraulic control system, adjustable side neat edge 10mm error.
4. The volume of the edge, according to customer’s demand, still can configure width shear device. To get ideal width materials. And configurable take-up 800mm(diameter)retreat solution frame.
Technic Specification:
Model | SH-861 | SH-861 |
Power Supply | 1 or 3 Phase | 1 or 3 Phase |
Max Width | 2450mm | 1830mm |
Working Speed | 0~64m/min | 0~64m/min |
Accuracy | 5/1000 | 5/1000 |
Power | 1.5KW | 1.5KW |
N. W/G. W. | 500/560kg | 450/510kg |
Packing Size | 2600*2100*2100mm | 2600*2100*2100mm |
Contact Us
- Yancheng Xiehe Machinery Co., Ltd.
- Contact nameEmily Guo Chat Now
- Phone0086-515-88335421
- AddressYimin Industrial Area, Yancheng, Jiangsu
