Home > Products > Amplifier > 2012 NEW Version APPJ PA0901A EL84+12AX7 Mini Tube Amp Black Tube Amplifier

2012 NEW Version APPJ PA0901A EL84+12AX7 Mini Tube Amp Black Tube Amplifier

FOB Price

Negotiable / Piece

10 Pieces(Min. Order)

Port shenzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	APPJ	Model Number	PA0901A
Type	Home Amplifier	Channels	3 (2.1)
Place of Origin	China

Product Description

Specifications

Integrated Tube Amplifier PA0901A
Tubes
Driver :6N4 (12AX7 or ECC83)
Power :6P14 (EL84 or 6BQ5)

2012 NEW version APPJ PA0901A EL84+12AX7 mini tube amp black tube amplifier

Integrated Tube Amplifier – PA0901A

A minimalist integrated amplifier with one pair of RCA inputs and a passive volume control to attenuate the output of its enhanced classical tube circuit comprised of a 6N4 (12AX7 or ECC83) twin triode feeding a single 6P14 (EL84 or 6BQ5) per channel, and also with our advanced switching power supply to deliver a 3.5 watts output per channel

This auction is include the tubes.

The tubes use 2* Shuguang 6N4+ 1* Shuguang

6P14 (China NOS tube ).

(Shuguang 6N4=EL84, Shuguang 6N14=12AX7)

You can replace the tubes (2*6N4+6P14) to (2*EL84+1*12AX7) by yourself.

Technical spcifications:

Tubes	Driver - 6N4 (12AX7 or ECC83)
Tubes	Power - 6P14 (EL84 or 6BQ5)
Power Output	3.5W+3.5W @ 8 ohms
Frequency Response	30-40Khz (+-1db)
Input Sensitivity	500mV
Signal-to-Noise Ratio	-80dB / 3.5W
Residual Noise	< 1mVac
Input AC Voltage	100-250Vac
Power Consumption	38W
Input Impedance	50K ohms
Output Impedance	8/6/4 ohms (Japan Z11-EI48*24 Output Transformers)
Input	RCA Jacks
Output	Banana Jacks
AC	Standard IEC Jack with Fuse protection (2A Fuse)
Note	Power cord is not included
