11kw power automatic 688 floor deck metal sheet roll former
- 30 Set / Sets per Month
- NEW PORT TIANJIN
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
11kw power automatic 688 floor deck metal sheet roll forming
-
11kw power automatic 688 floor deck metal sheet roll forming machine
-
11kw power automatic 720 floor deck metal sheet roll forming machine
-
trade anssurance 720 floor deck metal sheet roll forming machine for sale
-
best price of JCX -- 688 floor deck roll forming machinery corrugated roofing sheet machine
-
best price 688 floor deck metal roll forming machinery corrugated roofing sheet machine
Product Details
| Condition | New | Type | Tile Forming Machine | |
| Tile Type | Colored Steel | Use | Roof | |
| Production Capacity | 9-12m/min,2000pcs/day(8 hours work) | Place of Origin | Hebei, China | |
| Brand Name | JCX | Model Number | JCX--688 floor deck | |
| Power(W) | 11kw | Voltage | 380V 50HZ 3phase 1 phase voltage 220V | |
| Dimension(L*W*H) | 6800mm*12000mm*900mm | Weight | 4.3T | |
| Certification | TUV | Warranty | One year warranty maintenance free life | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Welcome to review our roll forming machinewe are manufacture
save space
excellent quality
complete service
Welcome to view 688 floor deck roll forming machine
according to customers requirements ,costom roll forming machine
panel picture
Technical parameters:
Our floor deck roll forming machine :
Pressed Steel Type | 688 | usage | ||
Effective coverage width | 688mm | |||
Expand Width (mm) | 1000(mm) |
steel bearing plate floor | ||
Thickness (mm) | 0.8 | 1.0 | 1.2 | |
Cross-section from the inertia (cm4 / m) | 91.62 | 119.38 | 142.01 | |
Cross-section to withstand the distance (cm3 / m) | 23.46 | 30.58 | 36.98 | |
Specifications
1. auto-tensioning coil inside the machine
a. mounted roll diameter
b. Maximum width 1000mm mounted volumes
c. Maximum load weight: 6000kg
d. Hydraulic Power: 3kw
e. Motor Power: 3kw
f. Cylinder diameter: 120mm
g. Working Pressure: 10Mpa
2 forming the host
a. Rack row floor: 24 rows: 24 steps
b. Spindle material 45 # steel modulation processing, diameter 80mm. Material 15GCR roller bearing steel processing HRC58-60 °.
d. Main motor power: 22kw
e. rolling speed :9-12m / min
f. stent 350 # steel welding jobs
g. Roll the surface of hard chromium plating thickness of 0.05mm.
3 Hydraulic Cutter
a. Blade material: Cr12 quenched
b. cut off system: the use of advanced hydraulic drive, forming automatically feet cut off, no deformation, no waste, a higher safety factor (host stop off)
4 Electronic Control System
a. OSD: The Taiwan and Taiwan reached 5.7-inch touch screen
b. the host computer (PLC): use of Taiwan and Taiwan reached DVP14ES
c. encoder: The South Korean Autonics ENC-1-1-1t-24
5 hydraulic system
a. use of Taiwan's advanced hydraulic system
b. Power: 4KW
2.Components
Components of line:
NO | Name | Unit | Qty |
1 | Manual decoiler | set | 1 |
2 | Main machine for roll forming | set | 1 |
3 | PLC Control system | set | 1 |
4 | Hydraulic system | set | 1 |
5 | Post cut | set | 1 |
6 | Stackinig | set | 1 |
•Noted:all the parameters can be changed as the customer's requirement,and different machine.
3.Sectional drawing
specialized manufacturer of roll forming machine,any requests just mail me.
Technical specification of every parts
1).decoiler: Optional
<1>. Manual un-coiler
|
real photo of machine:
| Production Description | |
|
Material of main equipment:
Roller material: high grade NO.45 forged steel, plated hard chrome on the surface of roller with thickness 0.05mm.
Active shaft material: high grade NO.45 carbon wrought steel at diameter 72mm.
Cutting blade: Cr12 mould steel with quenched treatment.
They are widely used as the roof of garden like factory, hotel, exhibition center, villa, civil construction, etc.
Material of main equipment:
Roller material: high grade NO.45 forged steel, plated hard chrome on the surface of roller with thickness 0.05mm.
Active shaft material: high grade NO.45 carbon wrought steel at diameter 72mm.
Cutting blade: Cr12 mould steel with quenched treatment.
They are widely used as the roof of garden like factory, hotel, exhibition center, villa, civil construction, etc.
Features of the production line
1)Professional designing for manufactures roofing & walling
2)Automatically continually manufactures high quality product with PLC.
3)Easy operation : Directly input the data on the touchable screen.
4)Customers decide the profile of products.
5)Saving time and cost owing to high speed running with hydraulic system.
6)One year warranty.
EXELLENT QUALITY AND COMPETITIVE PRICE!
CHOOSE US , CHOOSE THE BEST!
Thank you for your time!
