Downspouts Machine With Square&around for Sale
- tianjin
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Tile Forming Machine | |
| Tile Type | Colored Steel | Use | Roof | |
| Production Capacity | 8-15m/min | Place of Origin | Hebei, China | |
| Brand Name | JCX | Model Number | downspouts machine for sale | |
| Power(W) | 3KW | Voltage | 380V 3phase 50HZ | |
| Dimension(L*W*H) | 7000mm*1500mm*1500mm | Weight | 7ton | |
| Certification | TUV | Warranty | One year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1,we are manufacturer2,TUV quality certification
3,Saving time and cost
4,complete service
Square downspout roll forming machine/downspout machine for sale
Downspouts are drainage pipes that direct rain water from the roof to the ground. This is where the rainwater is lead away from the buildings foundation so that no rainwater is able to pool around the building. Downspouts are most commonly seen attached to the corners of home or building. Without perfectly working downspouts, rainwater will fall off the roofs edge and may cause flooding and damage to the building. Rain water will pass through the cracks in the walls, windows and into the buildings foundation.
The problem with downspouts is that they clog very easily when leaves, twigs, and other debris accumulate within the downspout itself. This makes it difficult for the rainwater to drain properly throughout the downspout.
Any debris that is found in the gutters should be removed. Running a hose through the gutters will reveal if there are any clogs in the downspouts. Downspouts are mostly attached to the house by downspout brackets, which can be easily removed for further cleaning if the downspout becomes highly clogged with debris.
At our gutters and downspouts are made up of aluminum, copper, copper penny aluminum, copper clad, euro copper, galvalume, galvanized steel, designer copper aluminum, lead coated copper, freedom gray copper, paint grip steel, preweathered zinc.
II. Square downspout roll forming machine/downspout machine for sale parameters
A. Composition of machine
Roll forming main machine………………………….…1 unit
10 Tons hydraulic de-coiler with coil car………….1 set
Punching system……………………………………2 units
Control panel…………………………………………..1 unit
Hydraulic station……………………………………1 unit
3M auto stacker……………………… ………………2 unit
Spare tools……………………………………………one box
B. Details of each composition
- Roll forming main machine
1. Coil width: 1000mm effective width:930+3-3 mm (design base on 3mm).
2. Working speed: 0-20m/min (not contain cutting and punching).
3. Roll station: 17stations material of roller: Gcr15 bearing material; polished and coated with chrome HRC58-62°.
4. Material of main shaft: 45 forge steel(Same as SAE1045) diameter roller: 150mm.
5. Main power: 45kw, forming thickness: 2.5mm—3.5mm, Transmission: by chain.
6. Roll former has leveling bolts in the base
- De-coiler
1. Single unrolling machine, one side can put material
2. Adopt automatic hydraulic system
3. Coil weight (Max):10000kg
4. Inter diameter: 470mm-520mm
5. Maximal out diameter:1800mm
6. Oil cylinder dia:120mm working pressure: 20mpa (=20Tons)
7. Coil width (Max.):1000mm
8. Working speed: 0-25m/min
9. Power: 5.5KW
10. Hydraulic power: 3kw
11. De-coiler should be with Loop control and hold down
12. Coil car: 10Tons
13. The motor power of coil car: 3Kw
14. Pressure: 12Mpa
- Control panel
(1)Voltage, Frequency, Phase: 380 V, 50 Hz, 3Phase
(2)Automatic length measurement:
(3)Automatic quantity measurement
(4)Computer used to control length & quantity. Machine will automatically cut to length and stop when required quantity is achieved
(5)Length inaccuracy can be amended easily.
(6).Control panel: Button-type switch and touch screen
(7)Unit of length: millimeter (switched on the control panel)
(8) Laguage: English, Spanish and Chinese
III. Square downspout roll forming machine/downspout machine for sale roller forming&working process


We provide the technical support for whole life. Meanwhile, if any parts go broken and not artificial damage, we will send you new ones for free. When need the technician to go abroad, we will arrange the technician. But the buyer should take all the cost, including Visa, Roundtrip ticket, suitable accommodation and pay the service fee to the technician with $50/days
We have been established in 1995 as a professional manufacturer of ROLL FORMING MALCHINE. We use AUTO CAD design software. With more than 10 years of experience and strict quality control, our products meet International Standard. We are the leading manufacturer of roll forming machine in China. We manufacture various kinds of roll forming machines for producing such products as Roof Tile, Wall Panel, Roofing Corrugated Sheet, Floor Deck, C & Z Purling, Highway Guardrail, Sandwich Panel, Container Board, Car Panel, Roll Shutter Door, Downspout, Decorated gusset, Steel Pipe, etc.
Q: Can you make the machine according to my design or prototype?
Q: What do you need to know so that I can have a machine plan from you for our technical people reference?
A: Well, as the basic needed information for designing a machine plan, pls see below details For the slitting line and cut-to-length: the material type(HR, CR, HDGI, PPGI, SS), thickness and width range, coil weight, cutting speed, slitting numbers(only for slitting line), steel plate required cutting length(only for cut-to-length line) For the C,Z,W Profile and roof/wall panel roll forming machine: the material thickness range, width range and the profile drawing are required(how many roll forming stands required are depended on the profile drawing) For the HVAC machine and the stainless steel pipe machine: the wall thickness range and the diameter range of the pipe Pls also provide us with your special requirements for the machine, for example, you want the machine to be a full-automatic one or semi-automatic one in order to save your procurement budget.
Q: How can we be assured that you will deliver us quality machine with spare parts?
A: We usually require our customers to send the technical people to our factory for checking the quality of the machine before shipping. Considering that the buyer usually is not very familiar with the machine assembling and debugging, so we send the technicians to the buyer`s factory for the installation of the machine provided that the Price Term was conclude on ALL IN basis. In additon, We provide all of our customers with the aftersales-service, its free of charge during the warranty period
