colorful stone chip coated steel roof tile machine
- 30 Set / Sets per Month
- NEW PORT TIANJIN
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
high quality stone coated metal roof tiles machine
-
stone coated metal roof tiles production line
-
metal shingle stone coated steel roof machine for sale
-
Color stone coated steel roofing making machine, stone coated metal roof tile machine for sale
-
stone coated roll forming machinery
-
stone coated metal roof panel cold roll forming machine
Product Details
| Condition | New | Type | Tile Forming Machine | |
| Tile Type | Colored Glaze Steel | Use | Roof | |
| Production Capacity | 3-4m/min,2000pcs/day(8 work hours) | Place of Origin | Hebei, China | |
| Brand Name | JCX | Model Number | JCX--Special color stone coating roof tile making machine made in Chin | |
| Power(W) | 30kw | Voltage | 380V 50HZ 3phase 1 phase voltage 220V | |
| Dimension(L*W*H) | 65*1.5*1.9m | Weight | 15T | |
| Certification | TUV | Warranty | One year warranty maintenance free life | |
| After-sales Service Provided | Overseas service center available |
Product Description
Specifications
Welcome to review our roll forming machinewe are manufacture
save space
excellent quality
complete service
Welcome to view JCX stone coated roof tile machine
according to customers requirements ,costom roll forming machine
panel picture & machine photo &production line
1. Auto bottom gule spraying section
Appearance size:4000*1000*2000 Unit:mm
Driving section:3KW Excitation motor or frequency speed regulation (AS per
customers’requirements )
Automatic pressure spray tank:1set capability:200kg Range:0.6~1Mpa
Automatic glue machine motor: Servo motor, Power:750w, plc
Automatic spray gun:4 set(spare parts)
Dust collecting fan: 1set power:200w
Damp proof lamp:1pc power:100w
Conveying device:Chain reciprocating
Air compressor:1set power:7.5kw
Dust control of axial flow fan:1set power: 200w
Agitator: 1set power:1.5kw
2 .Auto stone coated section
Appearance size:3500×1000×1500 Unit:mm
Framework: Steel welding
Conveying device:Chain reciprocating
Automatic sand hopper: 1set capability:200kg
Bucket lift:1 set
Manual sandblast gun:4sets
3.The first time drying section
Appearance size:25000×1000×1200 Unit:mm
Framework: Steel welding
Frame type thermal insulation wall: 1.2mm cold steel with Rock wool
Automatic temperature controller:4set Range:0°~160°
Infrared heating tube: 30pcs Power:30kw
Conveying device:Chain reciprocating
Air cooling device:1 set Power:200w
he first time drying section
4.Auto face gule spraying section
Appearance size:3000×1000×2000 Unit:mm
Framework: Steel welding
Damp proof lamp:1pc Power:100w
Automatic pressure spray tank:1set capability:200kg Range:0.6~1Mpa
Conveying device:Chain reciprocating
Automatic spray gun:4 set(spare parts)
Manual patch glue gun:4 set
Dust control of axial flow fan:1set power: 200w
Automatic glue machine motor: Servo motor, Power:750w
5.The second time drying section
Appearance size:30000×1000×1200 Unit:mm
Framework: Steel welding
Frame type thermal insulation wall: 1.2mm cold steel with Rock wool
Automatic temperature controller:4set Range:0°~160°
Infrared heating tube: 30pcs Power:30kw
Conveying device:Chain reciprocating
Air cooling device:1 set Power:200w
This line is 65.5 m long. So we need the warehouse length is about 75mm and one of 2*3 air compressor room.
About worker:
Panel loading one
Bottom spraying one
Stone coating one
Fill stone one
Face gule one
Bottom gule mixing one
Finish goods receiving one
EXELLENT QUALITY AND COMPETITIVE PRICE!
CHOOSE US , CHOOSE THE BEST!
Thank you for your time!
