20kw Racking System Metal Roofing Solar Mounting
- Xiamen
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | Sunrack | |
| Model Number | SFS-PR-01 | Specification | Normal | |
| Application | Commercial | Output Voltage (V) | 110/220 V | |
| Work Time (h) | 24 hours |
Product Description
20kw Racking System Metal Roofing Solar Mounting
1.Technical Specification--- Pithced Asphalt Shing Roof Mount
Material:Aluminum Alloy AL 6005/T5
Panel: Any Size,framed or thin film
Tilt Angle:0~60 degree
2.A Classical Case of Metal Roofing Solar Mounting
Pic 1
Pic 2
3. Necessary info. for us to design and quote
•What is your pv panels dimension?_____mm Length x_____mm Width x____mm Thickness
•How many panel are you going to mount? _______Nos.
•What kind of roof do you have?__________(Tin/metal/tile/slate/shingle roof)
•What is your planned pv assmebly block? ________Nos. in a row
•How is weather there,such as wind speed and snow load?___m/s anit-wind speed and____KN/m2 snow load.
4.Package for Metal Roofing Solar Mounting

5.Why u choose Sunrack Pitch Roof Mounted SolarPanel System ?
1.Easy Installation: The innovative Sunforson solar rail and G-Screw modules have greatly simplified the installation of PV modules.The System can be installed with a single Hexagon Key and standard tool kit.The SolarRoof system is aided by a very high level of pressembly.The G-Screw module and unique rail extension method allow greatly reduced installation times.
2.Great Flexbilitity: With the Sunforson Solar Roof mounting,frammed photovoltaic modules can be easily mounted on pitched roofs.The Solar Roof system has mounting accessories designed for use on almost every roof cladding available wiht unique rail .Excellent Compatibility.Designed as a unversal racking system,framed modules from all the popular manufacturers can be used.
3.High Accuracy: Without the need for onsite cutting,the use of our unique rail extending allows the system to be installed with millimetre accuracy.
4.Excellent Adaptability: The height adjustment of the rails from Sunforson allows a level PV array to be established,no matter how uneven the roof.Engineered To High Standard Sunforson SolarRoof is made to the highest standard,safe and strong its designed to Comply with AS/NZS 1170.
5.Maximum Lifespan: All components are made of quality extruded aluminium and stainless steel.The high corrosion resistance guarantees the maximun possible lifespan and is also completely recyclable.
6.Guaranteed Durability: Sunforson roof mounting provides a guarantee of 10 years on the durability of all components used.
6.CE Certification for Metal Roofing Solar Mounting
7.Sunforson Factory
