Customer trust BDXS-1224 3d stone carving cnc router
- Qingdao Tianjin Shanghai
- T/T Credit Card
You May Like
-
Sex Mini BDXS-3636 gem cutting and polishing machine
-
best service high quality factory price high efficient glass cutting machine
-
2015 hot new products cheap price tiger stone machine
-
Sex Mini new style BDXS-3636 cnc mechanical jewelry engraving machine
-
Heavy Duty cheap price high quality stone carving tool
-
cheap price high quality glass engraving machine
Product Details
| Condition | New | Type | Stone Cutting Machine | |
| Use | Marble | Production Capacity | 500sets/month | |
| Place of Origin | Shandong, China | Brand Name | Dipper | |
| Model Number | BDXS-1224 | Voltage | 220V 50/60HZ | |
| Power(W) | 3.0 KW | Dimension(L*W*H) | 3450x3050x1600mm | |
| Weight | 1500KG | Certification | CE | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
3d stone carving cnc router:1 cnc router for stone
2.NC-studio control system
3 factory supply
4 CE,ISO standard
Customer trust BDXS-1224 3d stone carving cnc router
Machine parts of 3d stone carving cnc router:
Samples of 3d stone carving cnc router:
Performance feature of 3d stone carving cnc router:
1)Industrial production model,heavy all-steel welded,temperating aging treatment,solid and can not change the shape.
2)It adopts Taiwan liner guide which is contact with the bearing surface,so long time use the precision will be high.
3)Germany double-nut automatic anti-backlash ball screw.
4)High speed driver,so it has high speed and power.
5)Dust-protected oiling structure,so it make sure the machine running long time.
6)Break point and cutting continued carving,so it can engrave at any angle.
7)It can compatible many kinds of CAD/CAM design software,such as tytp3,artcam. castmate and so on.
8)High power AC water cooling spindle,so it can process hard material efficiently.
Applicable industries of 3d stone carving cnc router:
Stone cnc router is used for carving marble,granite,glass,muyu-stone and so on hard materials.
Technical parameter of 3d stone carving cnc router:
Model | BDX-S90 | BDX-S12 | BDX-S15 | BDX-S18 |
X working area | 900 | 1200 | 1500 | 1800 |
Y working area | 1200-1500mm | 1200-1500mm | 1200-3000mm | 1200-3000mm |
Table size | 1080-1800mm | 1380-3000mm | 1680-3500mm | 1980-3500mm |
Max area of Z axis | 300mm | 300mm | 300mm | 300mm |
Highest running speed | 12m/min | 12m/min | 12m/min | 12m/min |
Highest engraving speed | 8m/min | 8m/min | 8m/min | 8m/min |
Precision | 0.005mm | 0.005mm | 0.005mm | 0.005mm |
Max feeding height | 350mm | 350mm | 350mm | 350mm |
Spindle power | 3.0kw/main axis | 3.0kw/main axis | 3.0kw/main axis | 3.0kw/main axis |
Rotated speed of the spindle | 0-24000rpm/min | 0-24000rpm/min | 0-24000rpm/min | 0-24000rpm/min |
Working model | stepper | stepper | stepper | stepper |
Machine weight | 1000kg | 1300kg | 1600kg | 2000kg |
More products about cnc router:
If any further details you need, please contact us with "contact" buttom.
Please feel free to contact us,we will reply within 24h!
We want to know:
1 How much the spindle power you need
2 What materials do you need to process
3 The size and thickness of the materia
The production process:
