Home > Products > Seaming Machine > Four Wheels Sealing Machine for Tin Cans/Tin Can Sealing Machine
Four Wheels Sealing Machine for Tin Cans/Tin Can Sealing Machine
- Ningbo
- T/T Credit Card
You May Like
Product Details
| Condition | New | Application | Beverage, Food | |
| Packaging Type | Cans | Packaging Material | Metal, Other, Metal, Plywood Case | |
| Automatic Grade | Semi-Automatic | Driven Type | Electric | |
| Voltage | 380V | Power | 2.2KW | |
| Place of Origin | Jiangxi, China | Brand Name | Gaoxin | |
| Model Number | 4A19 Sealing machine | Dimension(L*W*H) | 1000*917*1885mm | |
| Weight | 800KG | Certification | CE ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Four Wheels Sealing Machine for Tin Cans/Tin Can Sealing Machine
Model: 4A19 Four-wheel Sealing Machine
Technical Parameter:
| Productivity | 8-20 cans/min |
| Applied Sheet's Thickness | ≤0.5mm |
| Applied Can's Drive and Diagonal | 50-320mm |
| Applied Can's Height | 370mm |
| Motor Power | 2.2KW |
| Size | 1000*917*1885mm |
| Weight | 800KG |
Usage
The machine can be used for sealing of round and special-shapes cans of can-manufacturing and capacitor industry or other industries.
Other Sealing Machines:
1.Model: GT4A6 Sealing Machine
Technical Parameter:
| Productivity | 26-30 round cans/min, 15-20 special-shaped cans/min |
| Applied Can's Drive and Diagonal | 28-170mm |
| Motor Power | 1.5KW |
| Weight | 550KG |
| Size | 785*650*2000mm |
Usage:
| Productivity | 25-30 cans/min |
| Applied can's drive | 30-160mm |
| Applied can's height | 32-300mm |
| Motor Power | 0.37KW |
| Size | 790*600*1360mm |
| Weight | 200KG |
Usage:
| Productivity | 10-15cans/min |
| Applied can's diameter and diagonal | 40-350mm |
| Motoe Power | 1.1KW |
| Size | 800*650*2000mm |
| Weight | 400kg |
Jiujiang Gaoxin company is one of the largest-scale machinery manufacturing companies in China which specializes in capacitors (the shell and cover), filter sealing, cap ( aluminum cap, three and four lug caps, crown cap, pop-top cap), sealing, automatic feeding &NC (numerical control) punch etc. equipments.
1. Warranty: One year after shipment.
2. Delivery Time: 15-30 working days after receiving the advance payment.
3.Power:3 phase 4 wire, 380V, 50Hz(or according to your requirements)
4. Installation and commissioning
Before installation,we will provide machine layout drawing with dimensions, total power, single power, power interface, water &air input and output position, total water consumption. After the machines arrived and have taken seat,you must connect the water and electric and gas into the machines, then we shall send 2-3 technicians to install the production line.
