Pig and Chicken Manure Rotary Dryer Machine for Sale

Pig and chicken manure rotary dryer machine for sale

Chicken manure drying machine introduction:

 Chicken manure drying machine is mainly used to  the pollution of animal production produced by all kinds of breeding base. Such as cow dung, chicken manure, pig manure, goose feces and other waste, these wastes are normal after feeding livestock because the chicken, pigs and other livestock nutrition digestion ability can consume 25%, and 75% other nutrients in feed with the feces, if these feces through the dryer temperature, sterilization, deodorization and drying after the finished chicken manure containing nitrogen, phosphorus and potassium, organic matter, amino acid, protein and other ingredients, the chicken manure does not contain any chemical ingredients can produce high quality feed, fertilizer, organic fertilizer and other products, not only create economic benefits for the enterprise, and purification the breeding environment for customers, reduces the cost of breeding in the fertilizer plant, feed mill, and made great contributions to organic fertilizer processing industry.

Chicken manure drying machine is mainly used for water content about 65% all kinds of chicken manure, pig manure, cow, sheep, duck, goose feces, rabbit dung, sludge, waste water products, Slaughter Waste high moisture content the stench of livestock manure, decreased water content to 13% by high temperature drying and no peculiar smell, the machine up to the purpose of  high efficiency, deodorization and drying, dried chicken manure after re made of new material of  fish feed, pig feed, fruit tree fertilizer, organic fertilizer and other products directly  bring significant additional income to customers. The machine  widely used in large, medium and small type chicken factory, food factory, slaughterhouses, and organic fertilizer aquaculture industry.

 Technological process:

 Dehydration - mixing - feeding - drying - cooling - bagging

 Detailed process: raw material supply (chicken manure etc.) - dehydration - - - high temperature drying sterilization deodorant batching mixing - granulating - cooling - Screening - sealing - Finished product storage.

The consist of chicken manure:

This machine is mainly composed of a feed inlet, a drying cylinder, turning plate, transmission gear, outlet, separator, cyclone dust collector, gas filter, fan, hot blast stove, bracket, fan and other components.

Chicken manure drying machine working principle:

 Material from the feed port to centralized blanking drying cylinder inside plate .The cylinder drier under the drive gear  continuous rotation of the turning plate make the material under a rolling state, when the machine up to the set high the material natural fall to the bottom of the drying cylinder. During the material continuous rotation and fall  in drying cylinder the material  will rapid mix with  high speed wind heat,it form heat exchange of a certain wind speed , after material contact with strong heat material `s evaporation of water, the volatile gas and smoke will be sent to the  high-speed cyclone and flue gas dust removing device . In the state of rotation and rolling materials continue  forward slowly. After the material reach discharge port the material has been in the high temperature airflow complete drying, sterilization, deodorization. The machine is  environmental friendly and efficient drying .

Characteristic:

 1: High temperature drying, disinfection, sterilization, deodorant, insecticide, decomposition of harmful substances to retain their nutritional value, nitrogen content is 2.6%, the phosphorus content is 3.5%, the potassium content was 2.5%, crude protein 16-25%, organic matter was 45%. Chicken manure is the best choice of fertilizer pollution-free green food crop, it also can be used to feed the fish, cattle and pigs;

 2: Poultry waste recycling, open up resources, reduce the cost of feeding, reduce environmental pollution;

 3: High speed and temperature drying, suitable for large range of material humidity, good drying uniformity of products;

 4: A wide range of heat source, it can be used for different heat sources such as gas producer, direct heating hot air furnace, indirect hot blast stove, heat conductive oil, electric heating, steam and so on can be used as a heating source;

 5: The machine from the drying process or supporting equipment, is a precision design and cost-effective, without too many vulnerable parts, low maintenance cost.

 Parameter :
