1.6m Boat Azimuth Thruster / Rudder Propeller
- 80 Set / Sets per Month
- Shanghai China
- T/T Credit Card PayPal
You May Like
-
1.1m Diameter Marine Tugboat Azimuth Thruster
-
950mm Well Installation Rudder Propeller for sale
-
Transom installation Type Rudder Propeller Price
-
920KW Deck Installation Rudder Propeller / Azimuth Thruster
-
3000KW Marine Rudder Propeller / Azimuth Thruster
-
Well Installation Type Rudder Propeller / Azimuth Thruster
Product Details
| Place of Origin | Jiangsu, China | Brand Name | GATHERING Azimuth Thruster | |
| Model Number | SRP330 Azimuth Thruster | Part | Other, Thruster |
Product Description
Marine Rudder Propeller / Azimuth Thruster
The Azimuth Thruster get the certification of CCS, BV, RINA etc.
Functional Characteristics
· Rudder and thruster in one.
· Rudder propeller can steer in any direction of 360° above the water level
Advantage
· Provide all-around thrust
· Increase the operation flexibility of the vessel
Application
Large tugboat, harbor tug, drilling platform vessel, ocean engineering vessel
Installation Type
· Well installation
· Transom installation
· Deck installation
Marine Rudder Propeller Specification
Type | Input Power Max.(KW) | Input Speed Rated.(RPM) | Input Torque Max.(N.m) | Propeller Dia. Max. (mm) | Reduction Ratio | Weight(kg) |
SRP12 | 45 | 2300 | 200 | 500 | 1.93 | 65 |
SRP45 | 100 | 23502500 | 450 | 800 | 2.5 | 190 |
SRP85 | 210 | 2350 | 850 | 950 | 2.68 | 400 |
SRP138 | 260 | 2000 | 1380 | 1100 | 3.01 | 1200 |
SRP180A | 340 | 1800 | 1800 | 1150 | 3.46 | 1450 |
SRP180B | 280 | 1500 | 2.88 | |||
SRP180C | 180 | 1000 | 2.526 | |||
SRP226 | 350 | 1800 | 2260 | 1350 | 3.34 | 2000 |
SRP280 | 480 | 2800 | 1550 | 3.96 | 2100 | |
SRP310A | 580 | 3070 | 1550 | 3.718 | 2500 | |
SRP310B | 1500 | 3800 | 3.002 | 2600 | ||
SRP330 | 620 | 1800 | 3300 | 1600 | 4.04 | 2800 |
SRO330B | 620 | 1500 | 4100 | 3.26 | ||
SRP428A | 735 | 1800 | 4280 | 1600 | 4.35 | 4500 |
SRP428B | 1500 | 5220 | 3.671 | |||
SRP428C | 1000 | 7140 | 2.769 | |||
SRP550 | 920 | 1800 | 5423 | 1800 | 5.059 | 6000 |
SRP1000 | 1000 | 9762 | 2.804 | |||
SRP1150 | 1103 | 11500 | 1800 | 2.775 | 7000 | |
SRP1150A | 750 | 15280 | 2.102 | |||
SRP1450 | 1324 | 1000 | 14800 | 2100 | 3.257 | 17000 |
SRP1850 | 750 | 18500 | 2.44 | 18000 | ||
SRP1850B | 825 | 17900 | 2.68 | |||
SRP1850C | 900 | 16200 | 2.93 | |||
SRP2000A | 1545 | 525 | 30000 | 2200 | 1.925 | 20000 |
SRP2000 | 1471 | 750 | 20000 | 2.74 | ||
SRP2000B | 825 | 18800 | 3.01 | |||
SRP2000C | 900 | 17500 | 3.257 | |||
SRP2000D | 1000 | 16000 | 3.66 | |||
SRP2500A | 1912 | 750 | 31200 | 2450 | 3.32 | 24000 |
SRP2500B | 825 | 28360 | 3.453 | |||
SRP2500C | 900 | 26000 | 3.983 | |||
SRP2500D | 1000 | 26000 | 4.42 | |||
SRP3000A | 2206 | 750 | 31200 | 2650 | 3.32 | 28000 |
SRP3000B | 825 | 28360 | 3.453 | |||
SRP3000C | 900 | 26000 | 3.983 | |||
SRP3000D | 1000 | 26000 | 4.424 | |||
SRP4000A | 3000 | 750 | 42000 | 3200 | 4.41 | 53000 |
SRP4000B | 825 | 38200 | 4.85 | |||
SRP4000C | 900 | 35000 | 5.29 | |||
SRP4000D | 1000 | 32000 | 5.88 |
Packing details:Wooden case
Shipping date: 30~60 work days
Ⅰ.Warranty
12-month warranty, excluding the related parts
Ⅱ.Installation and Commissioning
A.We provide Layout Drawings & Installation Drawing after payment.
B. If needed, we will send engineers to the Buyer’s site for supervision of Installation and Commissioning.
Expenses abroad should be paid by the buyers.
Ⅲ. Inspection:
A. Customer visit factory;
B. We offer pictures for inspection;
C. The third party inspection appointed by Customers.
You will get the after-sale service all over the world. Convenient, Fast, High Efficiency, World-wide, etc.
Please contact us if you are interested in Marine Propeller, Thruster etc.
