China Wholesale Market 12PSB Fuel Diesel Injection Pump Test Bench for Cummin Spare Patrs

FOB Price

US$ 2,700 - 12,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

china wholesale market 12PSB fuel diesel injection pump test bench for cummin spare patrs

Product Description

Parameters

JHDS-5 Industrial Computer Type Test Bench			7.5KW	11KW	15KW	18.5KW
1	Rotation speed range of main shaft(rpm)		0-4000	0-3000	0-3000	0-3000
2	Motor output power(KW)		7.5	11	15	18.5
3	Pump output power(KW)		0.75	0.75	0.75	1.1
4	Height from center line of main shaft to work table(mm)		125	125	125	125
5	Rotation direction of main shaft		Positive Negative	Positive Negative	Positive Negative	Positive Negative
6	Testable cylinders of injection pump		12	12	12	12
7	Standard model of fuel injector		.
8	Oil injection count range		0-1000	0-1000	0-1000	0-1000
9	Capacity of oil tank(L)		>50	>50	>50	>50
10	Pressure of fuel system	High	0-4	0-4	0-4	0-4
10	Pressure of fuel system	Low	0-0.4	0-0.4	0-0.4	0-0.4
11	Supply oil capacity(L/min)		>10	>10	>10	>10
12	Temperature of fuel(°c)		40±2	40±2	40±2	40±2
13	Precise of fuel filter(μ)		5	5	5	5
14	Capacity of measuring cup(ml)		45/150	45/150	45/150	45/150
15	Pressure of air way (Mpa)	Positive	0-0.3	0-0.3	0-0.3	0-0.3
16	Pressure of air way (Mpa)	Negative	-0.05-0	-0.05-0	-0.05-0	-0.05-0
17	DC voltage(V)		12/1824	12/24	12/24	12/24
18	Package dimension(m)(L×W×H)		2.2×1.15×1.8	2.2×1.15×1.8	2.2×1.15×1.8	2.4×1.2×1.8
19	Weight(Kg)		900	900	1050	1050
