Product Details
| Place of Origin | Anhui, China | Brand Name | Yifang Zhijia | |
| Model Number | graphite | Type | Other, Sleeve, graphite | |
| Material | Bronze+Graphite |
Product Description
low-speed heavy other occasions graphite washers
The standard range of composite plain bearings is very comprehensive and covers almost every standard size. This range comprises straight and flanged bushings, thrust washers and strips.
Sleeve Bearings:
Model No. | Min. I.D. | Min.O.D. | Max.I.D. | Max.O.D. | Max. Length |
DU,SF-1 | 6mm | 8mm | 300mm | 305mm | 100mm |
DX,SF-2 | 10mm | 12mm | 300mm | 305mm | 100mm |
JF800 | 10mm | 12mm | 173mm | 180mm | 100mm |
FB090 | 10mm | 12mm | 300mm | 305mm | 100mm |
FB092 | 10mm | 12mm | 300mm | 305mm | 100mm |
JDB,JCB | 8mm | 12mm | 160mm | 180mm | 150mm |
FU | 1.5mm | 3mm | 50mm | 70mm | 70mm |
JGB | 1.5mm | 3mm | 300mm | 320mm | 100mm |
I.D. = inner diameter
O.D. = Outer diameter
Flange Bearings:
Model No. | Min. I.D. | Min.O.D. | Max.I.D. | Max.O.D. | Min.F.D. | Max.F.D. | Max. Length |
DU,SF-1 | 6mm | 8mm | 40mm | 44mm | 12mm | 53mm | 40mm |
JF-800 | 40mm | 46mm | 95mm | 105mm | 60mm | 144mm | 127mm |
FB090 | 25mm | 28mm | 300mm | 305mm | 35mm | 340mm | 90mm |
FB092 | 25mm | 28mm | 300mm | 305mm | 35mm | 340mm | 90mm |
JDB | 10mm | 14mm | 120mm | 140mm | 22mm | 170mm | 100mm |
FU | 6mm | 12mm | 50mm | 60mm | 14mm | 70mm | 70mm |
JGB | 6mm | 12mm | 300mm | 320mm | 35mm | 340mm | 130mm |
I.D. = inner diameter
O.D. = Outer diameter
F.D. = Falnge diameter
Technical Parameters:
Processing Form:
Our Advantages for bearing graphite
1.Very high sliding velocity
2.no external lubrication required
3.Maintenance-free operation
4.Good frictional properties
Application
graphite use high grade metal alloys as their base material, inlaid graphite and grease during the process of friction, it will release solid lubricant and lubricant oil automatically. The products are widely used in injection molding, automobile mold, engineering machine, food machinery and water turbines, etc.
DU bushes
DX bushes
Flange bearing
Bimetal bush
Bronze bush
Bimetal graphite bush
Bronze graphite wrapped bush
Bronze graphite bearing
Thrust washer
Ball retainer
Oilite bushes
