CE Approved 200kw Biogas Power Generator
- Qingdao
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | NPT | |
| Model Number | 200GFT | Output Type | AC Three Phase | |
| Speed | 1500/1800rpm | Frequency | 50/60HZ | |
| Rated Power | 200kw | Rated Voltage | 400/230V | |
| Rated Current | 360A |
Product Description
CE approved 200kw biogas power generator
CE approved 200kw biogas power generator
Generating set general Model | 200GFT | |
Structure | integral | |
Exciting method | AVR Brushless | |
Rated Power (kW) | 200 | |
Rated Current(A) | 360 | |
Rated Voltage(V) | 400/230 | |
Rated Frequency(Hz) | 50 | |
Rated Power Factor | 0.8 LAG | |
No load voltage setting range | 95%-105% | |
Steady state voltage regulation rate | ≤±1% | |
Transient state voltage regulation rate | ≤-15%—+20% | |
Voltage fluctuation rate | ≤3s | |
Steady state frequency regulation rate | ≤±0.5% | |
Transient state frequency regulation rate | ≤±10% | |
Frequency stabilization time | ≤5s | |
Line-voltage waveform sinusoidal distortion rate | ≤2.5% | |
Gas Engine | Model | ND119D20TL |
Type | V type 4 stroke, electric control ignition, pre-mixed lean burn, turbocharged after cooled | |
Cylinder number | 6 | |
Bore x Stroke (mm) | 132X145 | |
Total displacement (L) | 11.9 | |
Rated Power (kW) | 216 | |
Rated Speed (r/min) | 1500/1800 | |
Speed Regulation Mode | Electrical | |
Starting Mode | Electrical | |
Fuel type | Natural gas/biogas | |
Overall dimension (L x W x H)(mm) | 2650X1460X1880 | |
Net weight (kg) | 2250 | |
Features
Reliable Quality:
Rich Experience, advanced technology and good selection on all parts etc. have made our gas generator sets to be more reliable and durable.
Longer Life:
Good quality and regular maintenance will make our gas generator sets to keep a longer life. Usually the life will be about 5-10 years for small power; about 10-15 years for large power.
Competitive Price:
We would try our best to offer every customer a reasonable and competitive price based on equality and mutual benefit.
Best Service:
We have deeply known the importance of pre-sale service, after-sale service etc. for a long-term development and would be responsible for every product we sell.
High return rate of investment:
Most suitable customized design and solution, more competitive price, lower fuel consumption, lower maintenance cost and longer life etc. will make you to earn a high return rate of investment.
Certificate
different type of generator
Genset details
Pakaging and shipping
Advantage
Project site abroad
Customer visit and test
