Titanium anode and cathode for chlorinator
- 10000 Piece / Pieces per Month
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Shaanxi, China | Brand Name | CLTN | |
| Model Number | CLTN1003 | Application | for sodium hypochlorite producing, Swimming pool disinfection | |
| Technique | Brush painting | Dimensions | 100*100*1.0MM | |
| Grade | Coating: Ruthenium-Iridium, Gr1 | Powder Or Not | Not Powder | |
| Ti Content (%) | 99.6% |
Product Description
Specifications
Titanium anode and cathode for chlorinatorBase material: Gr2 titanium
Coating: Ru, Ir
SGS registered manufacturer
Titanium anode and cathode for chlorinator
Material | Gr1 Titanium as substrate, mixed Ruthenium-Iridium oxide or mixed Ruthenium-Iridium-Stannum-Titanium oxide as coating |
Technology | Sand blasting, Acid washing and Brush Coating |
Dimension & Shape | Different dimension and shape is available, or according to custom design/drawing |
Working Parameter | Current density≤2000A/M2 Temperature<60°C Max content of Fluoride ion is 200PPM |
Working Equipment | Sodium Hypochlorite Generator |
Working Principle | NaCL+H2O=NaCLO+H2↑ NaClO + H2O = HClO + NaOH HClO → HCl + [O] HCl + NaOH =NaCL+H2O |
Electrolyte | Salt water / Saline solution/ Brine/ Sea water |
Features | High current efficiency property High catalytic property Lasting working life Light weight electrodes Keep the operating voltage stably Produce NaCLO & Chlorine high efficiency |
Applications |
|
Remarks | Titanium anode also called MMO anode,DSA & Insoluble anode Cathode also be provided |
Packing | Plastic or paper as inside, carton or plywood case as outside, or according to client's demand |
MOQ | Flexible small sample order acceptable |
1. Substrate: pure titanium Gr2
2. Coating: Ruthenium and Iridium
3. Size:
Titanium mesh sheet 60*110*1.0mm, 7 pcs one unit
Titanium plate 0.6*63.5*150mm, 13 pcs one unit
Or size and design according to your request
4. Life span: 6000 hrs, 8000 hrs, 10000 hrs and 12000 hrs could be customized
5. Parameters:
Current density < 2000A/M2
Working temperatuer: 40-60 centidegree
Chlorine-liberated potential <=1.13V
Working environment: brine water
Reverse electrolysis frequency : 2 or 4 hours
6. MOQ: 2 units
7. Working principles:
NaCL+H2O=NaCLO+H2↑
NaClO + H2O = HClO + NaOH
HClO → HCl + [O]
HCl + NaOH =NaCL+H2O
8. Application: Sodium Hypochlorite(NaClO) production
9. Features:
a. High current efficiency property
b. High catalytic property
c. Lasting working life
d. Light weight electrodes
e. Keep the operating voltage stably
f. Produce NaCLO & Chlorine high efficiency
