HSS,straight shank Gold-P coated drills
- Dalian/Shenzhen
- T/T
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | USG | |
| Model Number | Gold-P Drills | Type | Drill Bit | |
| Machine Type | Drilling Tool | Certification | Other, ISO | |
| Material | Carbide | Processing Type | Forging | |
| Use | Other, industry & machinery |
Product Description
Specifications
1.HSS,straight shank Gold-P coated drills2.right hand spiral
3.point angle:118, normal point
4.bright body ,top TiN coating
item name : HSS , straight shank Gold-P coated drills
colors:gold & white
specifications:
flute diameter:1.0~13.0mm
flute length:18~114mm
overall length:40~152mm
Flute geometry: Right hand spiral
Point angle: 118 degree, normal point
Surface treatment: Bright body TiN coating on working part
Application: Drilling in steel, cast steel alloyed and Non-alloyed, gray cast iron, graphite, malleable cast iron.
Hardness:
Material | Carbon Steel | Carbon Steel | Alloy Steel | Stainless Steels | Titanium Alloys | Alminum Alloys,Zinc Alloys | Magnesium Alloys |
Hardness |
| ~HRc23 | HRc23~24 | ~HRc23 |
|
|
|
Strength | ~570N/mm² | ~830N/mm² | 830~1110N/ mm² | ~830N/mm² | ~410N/mm² |
|
|
HSS, HSS Co8 Gold-P Drills also available.
