Home > Products > LED light sources > 1W 8mm straw hat LED, DIP type,white color,120degree,120mA forward current;60-70lm

1W 8mm straw hat LED, DIP type,white color,120degree,120mA forward current;60-70lm

FOB Price

USD $0.65 - $0.69 / Piece

100 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin

Guangdong, China

Brand Name

RITA

1W 8mm straw hat LED, DIP type,warm white color,120degree,350mA forward current;60-70lm

Electrical / Optical Characteristics at TA=25°C
Parameter	Symbol	Min.	Typ.	Max.	Unit	Test Condition
Luminous Intensity	Φ	60	65	70	lm	IF = 350mA
Viewing Angle	2θ1/2	110	115	120	deg	IF = 350mA
Dominant Wavelength	Tc	6000	6500	7000	K	IF = 350mA
Spectral Line Half-Width	λD				nm	IF = 350mA
Forward Voltage	VF	3.0	3.3	3.6	V	IF = 350mA
Reverse Current	IR			10	μA	VR = 5V
Absolute Maximum Ratings at TA=25°C
Parameter	Maximum Rating
Power Dissipation	1W
Peak Forward Current (1/10 Duty Cycle, 0.1ms Pulse Width)	700mA
Continuous Forward Current	350mA
Reverse Voltage	5V
Operating Temperature Range	-40°C to + 55°C
Storage Temperature Range	-40°C to + 100°C
Lead Soldering Temperature [1.6mm(.063") From Body]	260°C for 5 Seconds
