infrared interactive whiteboard with intelligent pen tray

 we offer all kind touch screen, smart AD player, touch table, smart TV

      infrared interactive whiteboard

infrared interactive whiteboard in our workshop

82 inches interactive whiteboard in showroom

wire drawing aluminium alloy  frame

USB 2.0 cable

packaging for shipping

 packaging for shipping

our products in the fair

our products in the fair

What is the interactive whiteboard?

Interactive whiteboard turns your computer and projector into a powerful tool for teaching, collaborating and presenting. With a computer image projected onto the board, you can simply use your finger or any other non-transparent objects to access and control any application. You can work naturally at the board to take notes and highlight important information through the system. Whenever you meet, teach, train or present, STRIDETOP interactive whiteboard helps your group save time, increase interactivity and improve communication in the classroom.

Specifications

Induction manner:  infrared, multi-point

Power input:       USB power supply , AC 100-200V 50/60HZ 100mA

Signal interface :    USB2.0 cable

Data processing speed:   12m/s

Cursor speed:   200 points/s

Scanning speed:    The first point 25ms,consecutive points 8ms

Display ratio:   4:3 or 16:9

Anti-light intensity: can use under sunlight

Resolution:  4096*4096

Support system:  windows XP/Vista/WIN7/WIN8

Viewing angle:  170 degree in Horizon,160 degree in Vertical

Frame:  wire drawing aluminium alloy

Panel:    Honeycomb aluminum

Language:    English, Arabic, French, German, Italian, Russia, Spanish

Diagonal:    82 inches

Cursor speed:   180 point/s

Work Temperature:   Operating: -10°C ~ 75°C, Storage: -10°C ~ 85°C

Relative Humidity: 90%

Warranty:     1 year

Accessories: 3 plastic Pens, one Interactive Whiteboard Software CD, USB cable, wall mount parts, installation manual, warranty bill

Certificates:   CE/FCC/Rohs/ISO

Software function

Finger touch: user can use the finger other opaque objects to write and control the computer desktop on the board,two users can write simultaneously.

Annotation Function: Enabling embedded annotation to Microsoft TM Office series soft wares such as PPT, WORD, EXCEL and on-screen annotation to any application software;

Writing Functions: An array of selection to pen types such as normal pen, transparent pen, flat pen and textured pen and line width;

E-Blackboard Function: A selection of pages such as white page, black page, special effect background page, on-screen page with unlimited writing area;

Zoom Function: Zoom in/ out feature display;

Editing Function: Editing an object such as Copy, Delete, Move etc;

Spotlight Function: Spotlight focus movable, spotlight shape, color and transparency adjustable;

Screen Shade: Screen shade to hide and reveal screen from four edges of the screen;

Resources Library: Resources addible and delectable to make customized resources library;

Files Insertion: FLASH, PPT, Video and other files able to be inserted to the program text;

Record Function: Screen content and sound able to be recorded, saved, replayed and duplicated;

Camera Function: Camera for screen snapshots.
