Johnson filter screen/ Wedge wire v wrap screen pipe/tube
- tianjin
- T/T
You May Like
-
johnson filter screen
-
johnson type non-clogged water well screen
-
Johnson well screen rod base screen Continuous slot screen
-
wedge wire screen filter screen Welded Wedge Wire Screens
-
stainless steel water well screen johnson screen pipe for well drilling
-
stainless steel water well screen johnson screen pipe
Product Details
| Place of Origin | Hebei, China | Brand Name | guangxing | |
| Usage | Liquid Filter | Type | Filter Cylinder | |
| Material | Other, stainless steel | Hole Shape | Other, V shape | |
| Length | 3M 6M | Width | DIA 145 185 219MM |
Product Description
johnson filter Screens are manufactured by wrapping a shaped wire around an internal array of longitudinal rods. The wire and rod, generally made from carbon or stainless steel are joined by resistance welding. Screen sections are usually twenty feet long. The ‘V’ or wedge shaped profile wire wraps around the support rods over the full length of the screen creating a continuous and consistent slot opening. Most continuous wire wrap screens are manufactured from stainless steel in order to avoid problems associated with sand pumping that may result from accelerated corrosion of carbon steel screens.
Wire wrapped Well Screen | ||
Specification (Profile wire): | Width(mm): 1.50 1.80 2.30 3.00 3.30 3.70 | |
Specification (support rods): | Width(mm): 2.30 3.00 3.30 3.70 | |
Note: other wires and rods available upon request | ||
Slot size | 0.10, 0.15, 0.20, 0.25, 0.30…… 6.00mm also achieved upon request. | |
Material: | Low carton, low carton galvanized steel (LCG), stainless steel (304,316 etc.) | |
Length | 2.9 meters,3 meters,5.8 meters,6 meters. | |
Diameter | 1 1/2",2",2 1/2",3",3 1/2",4",6",7",8",9 5/8",10",12",133/8",14",16" | |
Screen end | Plain beveled ends for butt welding or threaded | |
Other sizes available on request .Deep well construction specifications available on question. Well depths :100 m, 200 m, 350 m & 600 m. | ||
Advantage
| Reduce energy consumption and increase water flow. Reduce erosion of entry surfaces and increase well life. Allow a uniform and efficient well development. Reduce significantly potential pump damage and subsequent maintenance costs. | |
