Drive in Pallet Racking

Specifications

The features of  drive in rack system:

1,Suitable for volume cargo with categories,forklift truck can drive into the aisle (passage way) .

2,stowing or picking cargo from the rack system,can realize “first in,last out”or “first in,first out”arrangement,

3,maximize utility rate of warehouse space,height range 2000-16000mm,load capacity 500-1500kg/pallet.

4,Many rack colors for your selection.

explain in detail:

Drive-in and Drive-through (sometimes spelled Drive-thru) are storage rack configurations that allow the forklift to drive directly into the lane of stacked rows (called a bay). The difference between a drive-in and a drive-thru pallet rack system is simply whether the bays have an entry at only one end, or at both ends. Drive-in rack systems use a common entry and exit, while drive-thru systems have entry points at either end of the bay. Because a drive-in racking system has only one entrance, it uses what is called a LIFO (last in, first out) storage method. With only one entrance, the last pallet put into a row is necessarily the first one to be taken out. A drive-thru storage system, with two different entry points, can also use a FIFO (first in, first out) storage method. With a FIFO system, pallets are loaded in one end and are pushed back to the other end, where they are then at the front of the row on the opposite side. The first pallet put into such a row is the first one taken out at the other end. This system is advantageous for material with an expiration date or wherever shelf life is a major concern.

Drive In rack system:

Drive-In rack system design factors:

Advantages of Drive-in rack system:

Drive-in rack system operations:

Plactical application:

our factory:

welcome clients to visit our factory.

Package:

Specific orders for warehouse racks are welcome.
