30 Ton Low Flatbed Semi Trailer, 3 Axle Flatbed Gooseneck Semi Trailers for Sale

Flatbed Semi Trailers for SaleDimension

Tare Weight

7800 kg

Payload

40000 kg

Overall Weight

47800 kg

Overall Length

12400 mm

Overall Width

2480 mm

Overall Height

1575 mm

Wheel track

1840 mm

Wheelbase

7450mm+1310mm+1310mm

40ft Flatbed Trailers for Sale Specification

Main Frame

Heavy duty and extra durability designed; Opting for high tensile steel Q345B, welding by automatic Submerged-Arc processes

500mm Height “I” beam, Top Flange 14mm, width 140mm; Middle Flange 6mm; Bottom Flange 16mm, width 140mm

Floor

Steel sheet 3mm thickness

Axle

Three units of 13T axle

Suspension

3-axle suspension, American design

Leaf Spring

Six sets of reliable leaf spring, 16*90mm or 100*12mm

King Pin

one unit of 3.5" bolt-in kingpin

Landing Gear

Two-speed, manual operation, heavy duty landing gear

Wheel Rim

13 units of 8.25-22.5 wheel rim

Tire

13 units of 11R22.5 tire

Twist Lock

Twelve nos. four nos are fasten mode, eight nos are up-down mode, of twist lock for 2x20ft, 1x40ft container, central locks can be laid down.

Spare Wheel Carrier

One set of spare wheel carrier including a riser.

Pneumatic Braking System

Two units of relay valve; four units of T30/30 spring brake chamber; two units of T30 brake chamber, two units of reliable local brand 45L air tank; two units of reliable standard coppery air-connector.

Electrical System

One unit of JAEGER POWAY, 24V 7-pin ISO 1185 socket; two sets of reliable, local brand standard rear light, turn light, rear reflector, side light, side reflector etc. One set of 6-core standard Cable.

Painting

Sand blasting before painting;

one coats of primer, anti corrosion;

two coat of finish painting;

colour advised by client

Accessory

One box with a set of standard trailer tool

Container Flatbed Trailers for Sale Payment & Terms

MOQ:

1 unit

FOB Price:

11000 ~ 13500 Per unit

Payment Terms:

L/C, T/T, Western Union

Supply Capacity:

500 Units per Month

Delivery Time:

About 25 Working Days

Delivery Port:

Shanghai

Package:

2 Units in 1x40HQ, CBU or CKD or SKD
