Airless Paint Spray Pump
US$ 1 - 1,000
/ Set
20 Sets(Min. Order)
- NINGBO/SHANGHAI
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | DINO-POWER | |
| Model Number | DP-H301 | Type | Airless Spray Gun | |
| Application | Paint Spray Gun |
Product Description
DP-H301 Pneumatic airless paint spray pump
Features include:
Proven quality of mechanical reverse system
High quality pneumatic airless paint sprayer with reliable Mechanical transducer / reverser, quick action and no ice low air consumption. Provides higher efficiency & minimum maintenance, for industrial usage.
Stainless steel fluid pump
H301 use Hardened stainless steel fluid pump and stainless steel piston rod, could be used for both oil-based and water-based coating
Durable v-packings
Teflon + Leather V-packings will always works like new, only replace it once per year. Save you time and money on your maintenance and repairing.
Compact size and light weight
Small size and light weight, ideal for furniture painting, factory, steel structure, etc. Commercial or industrial painting jobs which last 12 hours every day.
Built-in air filter group
Equipped with air filter regulator & lubricator for easy air controlling, filtering, and lubricating. Surely prolong the machine’s lifetime and performance.
Large manifold filter
The large manifold filter will always ensure you equal and nice finishing without pressure fluctuate. Meanwhile reduce the tip clogging also.
Pneumatic big wheels
The inflating pneumatic wheels for easy moving on rugged jobsite roads.
AAA (Air-assisted airless)
The h301 could be produced in air-assisted airless type, attached with AA airless gun, provide perfect atomization and great finishing results, especially for furniture woodworking nice finish.
Technical data:
Model No. | DP-H301 |
Fluid pressure ratio | 30:1 |
Max. paint delivery (L/min) | 12 |
| Max. Pump Speed | 100 cycles per min |
| Stroke (mm) | 100 |
| App. Air consumption at 6bar | 400~800 L/min |
| Air Compressor Pressure | 5-8 bar |
| Noise Level (dBa) | 56 |
| Maximum Discharge pressure | 256 bar |
| Air Inlet (inch) | 3/8 |
| Fluid Outlet (inch) | 3/8 |
| NM (kgs) | 46 |
| GW (kgs) | 45 |
| Packing size | 110*77*66cm |
| Contents in package | Airless pump, airless spray gun with tip, high pressure painting hose, repair kits, manual. |
