Original MBR3060 Schottky Barrier Rectifier Diode 30A 60V TO-220

FOB Price

US$ 0.01 - 1 / Piece

1000 Pieces(Min. Order)

Port Shanghai shenzhen or follow customer demand
Payment TermsT/T L/C D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	HC
Model Number	MBR3060	Type	Schottky Diode
Package Type	Through Hole	Max. Forward Voltage	0.8V
Max. Reverse Voltage	60V	Max. Forward Current	300A
Max. Reverse Current	1mA

Product Description

Absolute Maximum Ratings(Tc=25℃):

Characteristics	Symbol	Rating	Unit
Maximum Repetitive Reverse Voltage	VRRM	60	V
Average Rectified Forward Current	IF(AV)	30	A
Non-repetitive Peak Forward Surge Current 8.3ms Single Half-Sine-Wave	IFSM	300	A
Collector power dissipation Ta=25℃	Ptot	2.0	W
Junction temperature	Tj	175	℃
Storage temperature range	TSTG	-55~175	℃

Electrical Characteristics(Tc=25℃）:

Characteristics	Symbol	Test Condition	Min	Typ	Max	Unit
Forward Voltage	VF	IF=20A; TC=25℃			0.63	V
Reverse Current	IR	VR=100V; TC=25℃ VR=100V; TC=125℃			0.3 5	mA
Peak Repetitive Reverse Surge Current	IRRM	2.0 us Pulse Width,f=1.0KHZ TJ<175℃			2	A

Symbol	Parameter	Typ	Units
RθJA	Junction-to-Ambient	70	℃/W

Features:

 Low power loss,high efficiency

 High surge capacity

 For use in low voltage,high frequency inverters, free wheeling,and polarity protection applications

 Metal silicon junction,majority carrier conduction

 Guard ring for over voltage protection
