Home > Products > Bipolar junction transistor > TTA1943 PNP Transistors -230V -15A TO-3PL

TTA1943 PNP Transistors -230V -15A TO-3PL

FOB Price

USD $0.01 - $1 / Piece

100 Pieces(Min.Order)

Port Shanghai shenzhen or follow customer demand
Payment TermsT/T L/C D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	HC
Model Number	TTA1943	Type	Bipolar Junction Transistor
Package Type	Throught Hole

Product Description

Features:
-Power Amplifier Applications
-Complementary to MJ21196G
-High collector voltage: VCEO=-250V (min)
- High SOA:3A , 80V , 1Sec
- 250 WATTS

Note: Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the significant change in temperature, etc.) may cause this product to decrease in the reliability significantly even if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum ratings.

Absolute Maximum Ratings(Tc=25℃):

Characteristics	Symbol	Rating	Unit
Collector-base voltage	VCBO	-400	V
Collector-emitter voltage	VCEO	-250	V
Emitter-base voltage	VEBO	-7	V
Collector current	IC	-17	A
Base current	IB	-5	A
Collector power dissipation;Tc=25℃	PC	250	W
Junction temperature	Tj	150	℃
Storage temperature range	TSTG	-55~150	℃

Electrical Characteristics Tc=(25℃ ）:

Characteristics	Symbol	Test Condition	Min	Typ	Max	Unit
Collector cut-off current	ICBO	VCB=230V; IE=0			500	uA
Emitter cut-off current	IEBO	VEB=7V; Ic=0			500	uA
Dc current gain	hFE	IC=5A; VCE=4V;	70		140
Collector-emitter saturation voltage	VCE(sat)	IC=4A; IB=0.4A			0.5	V
Transition frequency	fT	VCE=10V; ICE=500mA ;f=1MHZ		58		MHZ

Symbol	Parameter	Typ	Units
RθJC	Junction-to-Case	0.83	℃/W

Related Products

* Below are part of general products provided by Thunder

* Package type could be adjusted according to customer needs

* New product (not in below list) could be developed according to customer needs

2SA1943	VCEO=-230V (min)	PNP TRANSISTORS	Complementary to 2SC5200
2SA5200	VCEO=230V (min)	NPN TRANSISTORS	Complementary to 2SA1943
MJ21195G	VCEO=-250V (min)	PNP TRANSISTORS	Complementary to MJ21196G
MJ21196G	VCEO=250V (min)	NPN TRANSISTORS	Complementary to MJ21195G
TIP42C	VCEO=-100V (min)	PNP TRANSISTORS	Complementary to TIP41C
TIP41C	VCEO=100V (min)	NPN TRANSISTORS	Complementary to TIP42C
2SA1837	VCEO=-230V (min)	PNP TRANSISTORS	Complementary to 2SC4793
2SC4793	VCEO=230V (min)	NPN TRANSISTORS	Complementary to 2SA1837
2SA1941	VCEO=-200V (min)	PNP TRANSISTORS	Complementary to 2SC5198
2SC5198	VCEO=200V (min)	NPN TRANSISTORS	Complementary to 2SA1941
