Mini Size HD DVB-T2 Digital TV Set Top Box Decoder dvb-t2 K2

Fully comply with DVB-T2, MPEG-2/4 H.264 Standard

HDTV/SDTV MPEG-2 & MPEG-4 H.264 decoding

Support 480i/480p/576i/576p/720p/1080i/1080P

HDMI output for High Definition

Support S/PDIF audio output

Support teletext/subtitle/multi-language

Support 7-day EPG

Channel edit function including Favourite, Move, Delete, Lock,Skip,Rename

Variable aspect ratio 4:3/16:94:3 Pan & Scan or Letter Box modes

Support USB 2.0 software upgrade and OTA software upgrade.

Support USB 2.0 PVR. MP3, AVI,DAT,MKV,MP4,MPG,VOB,WMA,BMP,JPG photo playback

  Chipset and Memory:

          CPU Speed: 550MHz MSTAR

          Flash:32Mbit

          RAM: 32X16Mbit  DDR2 Frequency1066

  Power:

          Input Voltage: AC 90~250V,50Hz/60Hz

          Maximum Power consumption: 10W

       Standby power: ≤ 0.3W

 Interface:

          ANT: x1

          Video/Audio output: RCA x1

          HDMI: x 1

          USB2.0 port for External USB PVR function: x1

Tuner:

             Tuner: DVB-T2

             Sensitivity Level:  - 10~ - 80dBm

 Demodulation:

             Compliant with: DVB-T2

             Demodulation: COFDM  QPSK,8PSK,16APSK,32APSK

             Guard interval Modes:1/4, 1/8, 1/16, 1/32

             FEC Mode:  1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10

Video Decoding:

            Compliant with:  MPEG-4 part10/MPEG-2 ISO/IEC13818

             MPEG-2 MP@HL,MPEG1 CC  ASP@L5 HD;H.264
             ISO/IEC14496-10 High profile up to level 4.0

             Support Meadia Format: H.264,MPEG1,2,4,DivX,                  TS,MKV,TP,AVI,M2TS,VOB,DAT,MPG,MPEG,MOV

         Aspect ratio: 4:3/16:9

             Video format: PAL/NTSC

             Resolution: 480i/480p/576i/576p/720p/1080i/1080P

Audio Decoding:

              Compliant with: MP3,WMA,MPEG-1 / 2 layer I / II,M4P, HE-AAC,COOK

Standard Accessories:

              DVB-T2 device*1

              Remote control(without battery)*1

              User manual *1

              Gift box*1
