Product Details

Place of Origin	Guangdong, China		Brand Name	RAEX
Model Number	M700

Product Description

Specifications

RAEX skylight motors m700
strong ,quiet,RF control and network control, easy to install ,ac motor

RAEX skylight motors m700

Features:
1.Strong, AC motor
2.RF control, switch and/or network control
3.Strong motor can pull skylights weighing up to 10 m²4.Stable mechanical limit system
5.Easy to install, easy to operate
6.Compact aluminum track available for straight and curve curtains

Parameters:

230V 50Hz

Product Name	Rated Voltage	Rated Frequency	Rated Power Input	Rated Torque	Rated Speed	Speed	Insulation Class	Protection Index	Running Time
M700	230V	50Hz	90W	1Nm	124rpm	0.16m/S	I.cl.E	IP41	S2 6min
M701	230V	50Hz	120W	2Nm	124rpm	0.16m/S	I.cl.E	IP41	S2 6minS2 6min
M702	230V	50Hz	190W	4Nm	124rpm	0.16m/S	I.cl.E	IP41	S2 4min
M710	230V	60Hz	140W	2Nm	124rpm	0.16m/S	I.cl.E	IP41	S2 6min

110V 60Hz

Product Name	Rated Voltage	Rated Frequency	Rated Power Input	Rated Torque	Rated Speed	Speed	Insulation Class	Protection Index	Running Time
M700	110V	60Hz	90W	1Nm	148rpm	0.16m/S	I.cl.E	IP41	S2 6min
M701	110V	60Hz	120W	2Nm	148rpm	0.16m/S	I.cl.E	IP41	S2 6min
M702	110V	60Hz	190W	4Nm	148rpm	0.16m/S	I.cl.E	IP41	S2 4min
M710	110V	60Hz	140W	2Nm	148rpm	0.16m/S	I.cl.E	IP41	S2 6min

M700 Measurement:260mmX55mmX55mm Net Weight: 1.53kg	M701 Measurement: 270mmX55mmX55mm Net Weight: 1.76kg
M702 Measurement:290mmX55mmX55mm Net Weight: 1.82kg	M710 Measurement: 270mmX55mmX55mm Net Weight: 1.83kg

Load Capacity(skylights):

Connection diagram:

Accessories:
