Home > Products > Petroleum Instruments > DSHY1001-I Cleveland Automatic Flash and Fire Point Tester
DSHY1001-I Cleveland Automatic Flash and Fire Point Tester
- CHINA
- T/T
You May Like
-
DSHP6002 Steam Pressure Tester for Liquefied Petroleum Gas
-
DSHD-6536C Low-temperature Distillation Tester
-
DSHD-3536-1 Automatic Cleveland Open Cup Flash Point Tester
-
DSHP9008-II Drop in Refrigerator
-
DSHP1013 Color Comparator for Lubricating Oil
-
DSHP2007-II Diesel Fuel Suction Filter for Cold Filter Plugging Point of Distillate Fuel
Product Details
| Place of Origin | Guangdong, China | Brand Name | dshing | |
| Model Number | DSHY1001-I | Power | Electronic | |
| Usage | Other, Automatic Cleveland Open Cup Flash&Fire Point Tester |
Product Description
A:Specifications
1.Flash & fire point pre-set, auto temperature rise
2.Automatic remote control ignition and sweeping
3.Temperature displaying
B: Standards:
GB/T3536, ASTM D92, ISO2592
C: Application:
applies to the determination of flash and fire point of petroleum products. This instrument applies to liquid and high
viscosity lubricating oil, but not applies to fuel oil and petroleum products with open flash point under 79°C
D:Function Features
- 5"Dot Matrix LCD display and soft keyboard operation; friendly human machine interface and software switching
between Chinese and English
— Support 4 standard testing mode: flash point, fire point, flash and fire point, flash point searching
— Self diagnosis and alarm triggering, sweeping, ascend and descend, testing, fire distinguish and result search
— 500 test results can be stored
— Gas ignition with built-in fuel gas control valve. The fire can only be ignited under safe test conditions
— Fast air cooling design to shorten the interval of continual testing
— External printer for easy printing of the test result at any time (optional)
— RS232 port for connection with LIMS system of the chemical laboratory
E:Technical Specification
— Power supply: 220±10% VAC, 50±1Hz
— Power: ≤1000W
— Dimension: 300mm (width) * 550 mm (Depth) * 350 mm (height)
— Weight: 30Kg
— Environment temperature: 5~35°C; 20-90% RH without condensation (35°C)
— Testing range of flash point: 80~370°C
— Testing method of flash point: anionic ring testing
— Ignition source: liquefied gas, butane gas, gas pipe, natural gas
— Pressure in ignition tunnel: <10kPa
