Home > Products > Insulation sleeving > Fiberglass wire sleeeves
Fiberglass wire sleeeves
- Qingdao&Shanghai
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | HX | |
| Model Number | 2715 | Application | WIRE | |
| Surface Treatment | SMOOTH | Dimensions | 1-30MM I.D. |
Product Description
Specifications
PVC fiberglass sleevingClass A
2. I.D. 0.5-40mm
3. BDV:1.5KV,2.5KV,4KV
4. Operating Temp.-25-130 degrees Celsiu
1. Temp. -25-130°C
2. Dia: 0.5-40mm
3. Color: Blue, green, red and straw yellow spiral lines or as per customers' requests.
4. Features: Smooth appreance, felxible body, good dielectric, chemical resistance, super elasticity, antiaging performance.
5. Technical Process: Made of non-alkly fiberglass braided sleeving coated with PVC (polyvinyl chloride) resin under high temp.
6. Applications: For wiring , radio, motors, appliances, electric instruments or apparatus and other electric equipment.
7. Breakdown voltage: 1.5kv, 2.5kv, 4kv, 7kv.
8. Packing: 1000mm/piece, 100m/roll.
SPECIFICATION:
Property | Units | Requirements | ||
Insulation resistance | At room temp | MΩ | 10³ | |
After damp heat | 10¹ | |||
Temperature index |
| 105 | ||
Breakdown voltage | Room temp | Central Value | kV | 4.0 |
Lowest individual value | 2.5 | |||
Elevated | Central | 1.2 | ||
Lowest individual value | 0.8 | |||
Damp heat | Central Value | 1.2 | ||
Lowest individual value | ||||
