HCC-L31 80MM Bluetooth Barcode Label Printer Android

Specification

Print

Printing Method

Thermal Line

Printing Speed

100mm/s ( Thermal Paper )
50mm/s ( Label Paper )

Resolution

8 dots/mm
576 dots/line

Effective Printing Width

72mm

Character

Character Set

ASCII, GB18030 (Chinese), BIG5

Print Font

Codepage, ANK: 9×17 / 12 x24,
Chinese: 24x24

Character per Line

48

Paper Spec

Paper Type

Thermal paper/Label Paper

Paper Width

79.5± 0.5mm

Paper Roll Diameter

40mm(max.)

Roll Core Inner Diameter

13mm(min.)

Paper Thickness

0.06~0.16mm

Paper Supply Method

Drop-in easy paper loading

Printer Mechanism

Fujitsu Brand

Reliability

MCBF(Mean Cycles Between Failure)

1.5 million lines

TPH

50km

Barcode

1D: EAN-13, EAN-8, UPC-A, UPC-E, CODE39, CODE93, CODE128, CODABAR, INTERLEAVED 25
2D: PDF417,QRCODE,DATA Matrix

Emulation

CPCL/ESC-POS

Driver

Windows 98 / ME / 2000 / NT / XP / 2003 Server/Vista/Win7/Win 8

Sensor

Paper End Sensor

Interface

USB/Bluetooth

Others

Button

Power, Feed, Mode

Indicator

Power, Feed, Mode

Memory

Flash: 512kb; RAM: 128kb

Receive Buffer Size

32K

SDK

Windows CE; Windows Mobile 5.0/6.0; Symbian; Blackberry and Android

Multi-languages

46 codepages

Power

Power Supply (Adapter)

DC9V/2A

Battery Power

 7.4V, 1.65A rechargeable Li-ion battery

Battery Charge

100m continuous printing

Charge Time

less than 3 hours

Battery Duration

360 hours

Physical

Net Weight

196g

Gross Weight

396g (Including battery & roll paper)

Printer Dimension(WxLxH)

104mm x109mm x 48mm

Color

Black

Environment

Operating Temp

-10-50°C

Operating Humidity

10%-80%

Application

Restaurants, Department Stores, Kitchen, Convenience Stores, Specialty Retail, Supermarket

Accessories

Battery,Charger USB Cable,CD Driver,Leather Case and Paper-roll
Option: vehicle charger

Inner Package
(WxLxH)

210mm x 155mm x 90mm(1.5kg)
