New material twin conductor electric heating mat for Europe and Russia Market
- Shanghai or Ningbo
- T/T D/P D/A Credit Card PayPal
You May Like
-
PVC insualtion aluminum braided shielded self regulating undergrond heating cable suitable for hazardous area
-
Popular style CE approved twin conductor self regulating undergrond heating cable suitable for hazardous area
-
Twin conductor self regulating undergrond heating cable suitable for hazardous area
-
60w/m self regulating ultrathin heating cable suitable for hazardous area
-
2016 new self regulating ultrathin heating cable suitable for hazardous area
-
Popular style CE approved solid heating core self regulating undergrond heating cable
Product Details
Place of Origin | Anhui, China | Brand Name | Huanrui | |
Model Number | F-mat | Type | Floor Heating Systems |
Product Description
New material twin conductor electric heating mat for Europe and Russia Market
F-mat is designed for wooden floor, laminate floor and under carpet heating .
F-mat can be cut and turned to achieve the required floor coverage and multiple mats can be joined together to cover large areas.When fitting underfloor heating ,a suitable insulation should always be used, (especially over concrete sub floors).
80W/m2 provided for customers choose .At 80W/m2 the electric heating system can be used as a Primary Heat source,or just for floor warming
F-mat use twin conductor heating cable with fluoropolymer insulation, and embed in a reinforced aluminium foil mat. The mat total thickness is ultra thin about 1.8mm, decreases the floor height and increases the comfort level
Technical Data |
Cable construction | Twin conductor |
Conductor | Solid heating core |
Insulation | Fluoropolymer |
Cable spacing | 50mm |
Cable diameter | 1.0mm |
Connector | Out splice |
Max Ambient Temp | 30 ℃ |
Min Installation Temp | 5 ℃ |
Rated voltage | 230VAC |
Power output | 80w/m2 |
Resistance tolerance | +10/-5% |
Cold lead | 2.5m length |
Warranty:
25 years. the defects against factory's material,design,workmanship
OEM service:
1.Sample: sample can be provided
2.OEM: Available
3.According to your preferences to design variety of parameters.
4.100% rate of response ,professional and smooth service
Sample available.just tell me the specifications.
Payment terms negotiable.
After-sale services available.
free design and installation guide.
Delivery time: normall within 7-15 days, large order should be negotiated.
Anhui Huanrui Heating Manufacturing Co.,Ltd is a china famous manufacturer & National hightech enterprises,which can research and development, production, sales and service the self regulating heating cable,Constant wattage heating cable,electric underfloor heating products,pipe heating cable.pipe freeze protection cable.pre-assembled heating cable kits,roof & gutter de-icing cable,snow melting cable & mat,concrete curing & drying cable,mineral insulated heating cable,accessories & thermostat etc. Company located in National science and technology innovative pilot city Hefei,found in 2004,the registered fund is 20.8 million RMB,have 100 pany own the first period building area 8476 square meters,have ten automatic production lines,the annual output is 20 million meters of self regulating heating cables. In 2015,Anhui Huanrui Heating manufacturing Co.,Ltd will invest 120 million RMB to the second factory project, covers an area 16500 square meters. Then Anhui Huanrui Heating Manufacturing Co.,Ltd will be the largest self regulating heating cable manufacturer provide the research and development, production, sales and service
New material twin conductor electric heating mat for Europe and Russia Market for indoor house packing:usually packind in white neural box, then packed into carton box. if big order with large quantity. will provide the customized service. such as the cable marking.adhesive tape with logo,individual color box or other order requestments.
Floor heating mat shipping: customer can choose the carton box packing by pallet or without pallet.the delivey type can be by sea,by air, by train,by truck.by international express.
