Home > Products > Shotcrete Pump > High quality/portable concrete pump Made-in-China
High quality/portable concrete pump Made-in-China
- Shenzhen
- T/T
You May Like
Product Details
| Power Type | Electric | |||
| Place of Origin | Guangdong, China | Brand Name | TS | |
| Model Number | TS7-6-11D | Weight | 960 KG | |
| Dimension(L*W*H) | 2500X1010X1450mm |
Product Description
Specifications
small size, superior performance,low maintenance costs, ease of operation,
flexibility, wide range of applications
Hot Sell Wet concrete spraying machine,concrete sprayer
TS7-6-11D multi-function wet spraying machine, mainly used for wet spray high way, railway, mine tunnel , wall grouting in people building, fine stone and concrete pumping of construction use and so on . Using internationally generalduty hydraulically driven wet spray technology, delivery distance and conveying height are 3 to 5 times higher than the rotor wet spraying machine.
1.The discharge of the wet spraying machine can be stepless variable, and the delivery discharge is 0-7m³/h
2.This machine achieve the power by the hydraulic. Using high pressure hose to connect the exist . The nozzle connect to small size 10m³ air compressor, achieve the wet spraying function. Change the technology of using the big size 20m³ wind power air compressor.
3.Compare with the rotor wet spraying wind power wet spraying machine, this hydraulic wet spraying machine with small size, superior performance, low maintenance costs, ease of operation, flexibility, wide range of applications and so on .
TS7-6-11/15D Technical performance
Parameter | Unit | Data | |
Productivity | m3/h | 7 | |
Max. particle size | mm | 15 | |
Fineness modulus of aggregate |
| ≥2.5 | |
Dosage of liquid accelerator | % | 3.5 | |
Hose diameter | mm | 51 (2″) | |
Concrete slump | cm | 8~15 | |
Systematic wind pressure | MPa | ≥0.5 | |
Outlet pressure | MPa | 6 | |
Wind consumption | m3/min | ≤6 | |
Max. conveying distance | Horizontal | m | 300 |
Vertical | m | 80 | |
Dust alongside machine | mg/m3 | <6 | |
Rebound(Under standard technology) | % | Average≤15 | |
Motor power | KW | 11/15 | |
Gauge | mm | 600,762,900 | |
Overall dimension(Tyre type)(L×W×H) | mm | 2500×1010×1450 | |
Weight | kg | 960 | |
