EPS Machinery (EPS Batch Pre-expander)
- Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Shanghai, China | Brand Name | HiSuccess International | |
| Model Number | PEB1200, PEB1400, PEB1600 |
Product Description
Features:
Safety systems, monitoring the production process
Weight control of raw material, measuring by sensor
Vibrating system, avoiding beads agglomeration
Stainless steel pressure vessel with thermal-insulating layer, preventing beads condensate
Temperature controlling system
Main Parameters:
Specification | Unit | PEB1200 | PEB1400 | PEB1600 |
Chamber Diameter | mm | 1200 | 1400 | 1600 |
Chamber Height | mm | 2000 | 2000 | 2000 |
Effective Volume | m3 | 2 | 2.7 | 3.5 |
Steam Pressure | MPa | 0.3 ~ 0.6 | 0.3 ~ 0.6 | 0.3 ~ 0.6 |
Compressed Air Pressure | MPa | 0.4 ~ 0.7 | 0.4 ~ 0.7 | 0.4 ~ 0.7 |
Density | kg/m3 | 6 ~ 25 | 6 ~ 25 | 6 ~ 25 |
Capacity | kg/h | 200 ~ 600 | 400 ~ 1000 | 500 ~ 1200 |
Power | kw | 29 | 33 | 33 |
Voltage | V/HZ | 380/50 | 380/50 | 380/50 |
Weight | kg | 2300 | 2600 | 3000 |
Contour Size | mm | 7600*3100*4200 | 7600*3500*4200 | 7600*3700*4200 |
