Turbine Heat Circulation Shrink Tunnel

Condition	New		Application	Food, Beverage, Commodity, Medical, Chemical, Other, Apparel, Textiles, Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware, Apparel, Textiles
Packaging Material	Plastic		Automatic Grade	Automatic
Driven Type	Electric		Voltage	380v
Power	16kw		Place of Origin	Guangdong, China
Model Number	T-63		Dimension(L*W*H)	2200x1000x1230mm
Certification	CE		After-sales Service Provided	Engineers available to service machinery overseas

Specifications

Shrink Tunnel
1.CE certificate
2.Turbo hot air flow circulation
3.Lower heat lost to surrounding
4.More conveyor systems

   Established in 2004, Nanjing Jinhuigu Industrial Trade Co., Ltd. is a specialized supplier of packing materials, packing machinery, plastic processing equipment and other materials.

Specifically, our main products include polyolefin/PVC shrink film, PVC cling film, PE stretch film, and other packing material. Moreover, we are also cooperated with qualified manufacturers to making plastic processing equipment according to the requirement of clients, such as triple bubble line for producing barrier shrink film, slitter and folder, and special wrapping shrink equipment.

Since the establishment, we have been devoting ourselves to developing various sources according to the requirement of our clients. We are not only importing and exporting various products as an authorized agent from manufacturers, but also a representative of some North American and European companies in China. We have obtained good reputation and built excellent relationships with various manufacturers both domestic and overseas.

Presently, we are looking forward to even greater cooperation with overseas customers based on mutual benefits. Please feel free to contact us for more details.



VIEW OF HALF-FINISHED SHRINK MACHINE





VIEW OF FACTORY







T63  TURBINE HEAT CIRCULATION SHRINK TUNNEL



Features:

1.Installed turbo hot air flow circulation;

2.Highly reduce heat up time;

3.Lower heat lost to surrounding;

4.Diminish the use of energy;

5.The lateral air flow directions of both sizes are adjustable;

6.Bottom air flow strength can be manipulated;

7.Different conveyor systems are available(Live roller,Stainless steel or Teflon mesh)





Uses:

 Tin cans, bottles, soya sauce, daily-use products, cosmetic products, candies, electronic appliances, stationery, gift boxes, greeting cards, photo albums, etc.





Model	T-61	T-62	T-63	T-64	T-65
Machine Size (mm) L x W x H	1450x860x1080	1700x900x1160	2200x1000x1230	2200x1090x1230	2200x1250x1180
Chamber Size (mm) L x W x H	1100x310x200	1200x350x280	1700x450x350	1700x540x350	1700x700x280
Maximum Packing size(mm) W x H	260x150	300x230	400x300	500x300	650x230
Power	3p,380v,12kw	3p,380v,14kw	3p,380v,16kw	3p,380v,18kw	3p,380v,23kw
Conveyor speed	0-30m/min

   *Tailor made version is available







OPTIONAL ACCESSORY:

Observation window





Pressing roller



Mesh conveyor





Opening of chamber
