concert stage background full color SMD3528 p7.62 indoor led screen

FOB Price

USD $600 - $1,000 / Square Meter

1 Square Meter(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

concert stage background full color SMD3528 p7.62 indoor led screen

Features:

1.Quick and easy assembling and dismantling

2.abinet back view energy-saving and environment-protection

3.High Refresh Rate, High Gray Scale, High Brightness Effective

4.Energy saving IC and special design of circuit diagram, power consumption to be decreased by 35-50%

5.Flat screen, no gap. Cabinets were made by high-precision molding plastic injection, no slit on the screen.

6.Professional radiant calibration system to make sure the color and brightness uniformity.

7.Perfect heat ventilation, good water proof and stable performance.

Specification:

No.	Specifications	Project
1.	Model	led display for indoor p7.62
2.	LED chip	Epistar/Silan/Cree etc...
3.	Physical Pixel Pitch	7.62mm
4.	Physical Pixel Density	17220dots/m 2
5.	Pixel composition	SMD,1Red, 1Green,1Blue
6.	Moduel Size	244*122mm
7.	Moduel resolution	32*16dots
8.	Cabinet size	976x976mm
9.	Bracket of cabinet	Easy to install onto the LED cabinet and unistall .
10.	Brightness	≥ 1500cd/ m 2
11.	Colors	16.7million
12.	Viewing angle	Horizontal ≥120°, Vertical : ≥ 120°
13.	Viewing distance	5m -100m
14.	Scan frequency	≥600 Hz There will be one receive card in each cabinet ,so that the LED display wont sparked . Also it is very easy to move and connetct
15.	Video Frame Rate	≥150 fps
16.	Control method	Controlled by PC, synchronous display
17.	Life span( half brightness)	≥100,000 hours
18.	Weight	45Kg /sqm
19.	Average power consumption	300W/sqm
20.	Peak power consumption	800W/sqm
21.	Input voltage	AC220V/50Hz ±10% or AC110V/60Hz ±10% or AC380V/60Hz ±10%
22.	Operating Environment	Temperature:-20+60 Humidity:10%95%RH
23.	Operating system	Windows 7/Vista
24.	Type of video signal	S-video, composite video ,RGB ,VGA ,DVI

concert stage background full color SMD3528 p7.62 indoor led screen
