Home > Products > Hydraulic Cylinder Rod > SUS304 Hydraulic Cylinder Hard Chrome Plated Steel Round Bar
SUS304 Hydraulic Cylinder Hard Chrome Plated Steel Round Bar
US$ 2 - 5
/ Kilogram
1000 Kilograms(Min. Order)
- Shanghai
- T/T
You May Like
-
AISI431 Hydraulic Cylinder Hard Chrome Plated Steel Round Bar
-
E355 Hydraulic Cylinder Hard Chrome Plated Steel Round Bar
-
ST52 Hydraulic Cylinder Hard Chrome Plated Steel Round Bar
-
SAE1045 Hydraulic Cylinder Hard Chrome Plated Steel Round Bar
-
SCM440 Hydraulic Cylinder Hard Chrome Plated Steel Round Bar
-
SAE4140 Hydraulic Cylinder Hard Chrome Plated Steel Round Bar
Product Details
| Steel Grade | SUS304 | Standard | AISI, ASTM, BS, DIN, GB, JIS | |
| Dimensions | 6 mm 1000 mm | Place of Origin | Shanghai, China | |
| Brand Name | AB STEEL | Application | Tool Steel Bar | |
| Alloy Or Not | Non-alloy | Type | Other, Carbon Steel Bar, normal;hollow bar,induction hardened |
Product Description
Specifications
SUS304 Hydraulic Cylinder Hard Chrome Plated Steel Round Bar1.Grade: SUS304
2.Hard Chrome Plate Thickness: 15 to 40 Micron
SUS304 Hydraulic Cylinder Hard Chrome Plated Steel Round Bar
Product Description
SteelGrade:
CK45/S45/SAE1045,SCM440/SAE4140,EN8D,ST52,16Mn,20Mn,E355,AISI431,SUS304/316
Supply Condition:
ground and chrome plated, tempered
Type:
normal;hollow bar,induction hardened
Metric OD Size:
6 mm 1000 mm
Inch OD Size:
1/4" to 50"
Hard Chrome Plate Thickness:
15,20,25,30 Micron (or according to customer's request)
Surface Roughness:
Ra < 0.4 Micron
Tolerance:
ISO f7,f8,H7,H8
Ovality:
half of the OD tolerance
Straightness:
<0.2 mm/m
Salt Spray Test:
ASTM B117-72hours/96hours,results evaluation refers to ISO4540 Rating 8-10.
Induction Hardening Chrome Rod can also be supplied, we can supply machining survice according to detailed draft and other technic request can be discussed.
Packaging & Shipping
Anti rust oil on material and packed first by cardboard sleeve then in steel frame box.
Delivery Time: 30 to 60 days after order confirmed.
