CK45/S45/SAE1045 Chrome Plated Bar/ Hydraulic Cylinder Piston Rod/Piston Shaft

FOB Price

US$ 1.5 - 5 / Kilogram

800 Kilograms(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Chrome Plated Bar/Hydraulic Cylinder Piston Rod/Piston Shaft
Steel Grade:CK45/S45/SAE1045,SCM440/SAE4140,EN8D,ST52,16Mn

Chrome Plated Bar/Hydraulic Cylinder Piston Rod/Piston Shaft

Steel Grade:CK45/S45/SAE1045,SCM440/SAE4140,EN8D,ST52,16Mn,20Mn,E355,AISI431,SUS304/316

Type:normal;hollow bar,induction hardened

Metric OD Size: 6 mm 1000 mm Inch OD Size: OD 1/4" to 50".

Hard Chrome Plate Thickness: 15,20,25,30 Micron (or according to customer's request)

Surface Roughness:Ra < 0.4 Micron

Tolerance: ISO f7,f8,H7,H8

Ovality: half of the OD tolerance

Straightness: <0.2 mm/m

Salt Spray Test: ASTM B117-72hours/96hours,results evaluation refers to ISO4540 Rating 8-10.

Package:anti rust oil on material and packed first by cardboard sleeve then in steel frame box.

We can supply machining survice according to detailed draft and other technic request can be disscussed.

For more information, please send an email to Jenny(at)

Shanghai Anbao Industry Co., Ltd.: Contact nameBruce Lee
Chat Now; Phone0086-21-61996260; AddressRoom 1502, No. 61, Nanjingdong Road
