Free Magic Arm + F&V F3 | 7" H DMI + HD-SDI Monitor

This monitor comes equiped with peaking, black & white, and horizontal/vertical image flip. The F3 monitor automatically detects whether the signal is NTSC or PAL, and you can choose whether to display in either a 16:9 or 4:3 aspect ratio.

This HDMI model features Composite RCA, Composite BNC, and HDMI connections.The monitor also comes with a built in Sony NP-F battery plate. The F3 monitor offers versatility at a price point you can't ignore.

Features:

• ›HDMI & HD-SDI Connectivity
• ›LED Backlight Display
• ›Automatically detects NTSC or PAL
• ›Selectable Aspect Ratio 16:9 or 4:3
• ›1024 x 600 Pixels
• ›View in Color or Black & White
• ›Vertical Image Flip
• ›Efficient Power Consumption
• ›Wide Range of Operating Voltages
• ›Focus Assist
• ›Built in battery plate

Specification:

Screen Size: 7.0” (diagonal)

Display Area: 153.6mm(H) x 90mm(V)

Aspect Ratio: 16:9/4:3 Selectable

Pixels: 1024(H) x 3(RGB) x 600(V)

Selectable Color Depth: 24-bit (16,777,216 colors)

Brightness: 400 cd/m²

Contrast Ratio: 800:1

Viewing Angle: 170°

Dot Pitch: 0.15(H) x 0.15(V)

Compatible Input Formats: Composite – NTSC/PAL; HDMI – 480i/p, 576i/p, 720i/p, 1080i/p 50/60HZ

Operating Voltage: 5.8 – 16.8V DC

Power Consumption: 0.5Amp (Max) @ 12VDC

Audio Power: 1W max

Video Input/Output: HDMI / AV1 / AV2 / HD-SDI

HDMI Input: HDMI (Type A) Female

Audio Input/Output: RCA Female (8)

Nominal Weight: 15 oz / 425 g (excluding battery)

Nominal Dimensions (L x W x H): 17.5 × 13 × 3.2 (cm)

Package Contents

(1) x F3 7" LCD Monitor - HDMI & HD-SDI

(1) x Snap-on Sunshade

(1) x HDMI Cable

(1) x Ball Head

(1) x User Manual

(1) x  Warranty card

 (1) x Free 11 inch magic arm
